FCC ID 2AC49-M06USA1
WLAN 802.11/b/g/n module
by Sichuan Changhong Electronic Component Co., Ltd.
Grantee Code: 2AC49 Product Code: M06USA1
Latest application date: 2016-12-27
Device Images
FCC ID Device Details
| FCC ID | 2AC49-M06USA1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AC49 |
| Product Code | M06USA1 |
| Applicant Business | Sichuan Changhong Electronic Component Co., Ltd. 🇨🇳 |
| Related Domains |  changhong.com |
| Equipment Class | WLAN 802.11/b/g/n module |
| Test Firm | Shenzhen BALUN Technology Co.,Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-12-27 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_WIFI-2-M06USA1 UserMan,r1 | Users Manual | 2016-12-27 | PDF 1.6 MB |
| 09_WIFI-2-M06USA1 IntPho | Internal Photos | 2016-12-27 | PDF 284.7 KB |
| 08_WIFI-2-M06USA1 ExtPho | External Photos | 2016-12-27 | PDF 284.7 KB |
| 06-07_WIFI-2-M06USA1 LabelSmpl-Loc | ID Label/Location Info | 2016-12-27 | PDF 134.8 KB |
| 17_WIFI-2-M06USA1 AntSpec | Operational Description | 2016-12-27 | PDF 12.5 KB |
| 10_WIFI-2-M06USA1 TSup,r1 | Test Setup Photos | 2016-12-27 | PDF 187.6 KB |
| 14_WIFI-2-M06USA1 TestRpt,r2 | Test Report | 2016-12-27 | PDF 3.8 MB |
| 18_WIFI-2-M06USA1 RFExp | RF Exposure Info | 2016-12-27 | PDF 58.1 KB |
| 12_WIFI-2-M06USA1 BlkDia Metadata only | Block Diagram | PDF 13.4 KB | |
| 13_WIFI-2-M06USA1 Schem Metadata only | Schematics | PDF 30.9 KB | |
| 11_WIFI-2-M06USA1 OpDes,r1 Metadata only | Operational Description | PDF 72.5 KB | |
| 16_WIFI-2-M06USA1 PartsLst Metadata only | Parts List/Tune Up Info | PDF 38 KB |
Application Information
| Application ID | cMQvaLCoJ8nu61xLAKBF1Q== |
|---|---|
| Final Action Date | 2016-12-27 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023737281 |
| Model | M06USA1 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WLAN 802.11/b/g/n module |
| Responsible Party | Jiangyuan Wei, Manager, jiangyuan.wei@changhong.com , +86 13568428012 |
| Test Firm | Xuewen Wu, Shenzhen BALUN Technology Co.,Ltd., xuewen.wu@baluntek.com  , 86-755-66833404 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. This device supports 20MHz and 40MHz bandwidth operation. Limited Modular Approval (due to lack of RF shielding). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| cMQvaLCoJ8nu61xLAKBF1Q== | 2016-12-27 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.2052000 | 15C |
Grants
TCB Grant - Application cMQvaLCoJ8nu61xLAKBF1Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 12/27/2016 Application Dated: 12/27/2016 |
| Sichuan Changhong Electronic Component Co., Ltd. |
| Luosheng street, Huagai Zhen, Anxian, Mianyang |
| Sichuan, China |
| Attention: Jiangyuan Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC49-M06USA1 |
| Name of Grantee: | Sichuan Changhong Electronic Component Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN 802.11/b/g/n module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.2052 |
| Power listed is conducted. This device supports 20MHz and 40MHz bandwidth operation. Limited Modular Approval (due to lack of RF shielding). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
EAS Grant - Application cMQvaLCoJ8nu61xLAKBF1Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sichuan Changhong Electronic Component Co., Ltd. Luosheng street, Huagai Zhen, Anxian, Mianyang Sichuan, China |
Date of Grant: 12/27/2016 Application Dated: 12/27/2016 |
| Attention: Jiangyuan Wei , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC49-M06USA1 |
| Name of Grantee: | Sichuan Changhong Electronic Component Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WLAN 802.11/b/g/n module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.2052 |
| Power listed is conducted. This device supports 20MHz and 40MHz bandwidth operation. Limited Modular Approval (due to lack of RF shielding). Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
| Mail To: |
