FCC ID 2AC9MGPT2541GNAC
Equipo para acceso Fibra Optica
by Wuxi MitraStar Technology Co.,Ltd
Grantee Code: 2AC9M Product Code: GPT2541GNAC
Latest application date: 2016-09-26
Device Images
FCC ID Device Details
| FCC ID | 2AC9MGPT2541GNAC |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AC9M |
| Product Code | GPT2541GNAC |
| Applicant Business | Wuxi MitraStar Technology Co.,Ltd 🇨🇳 |
| Related Domains |  mitrastar.cn |
| Equipment Class | Equipo para acceso Fibra Optica |
| Test Firm | MRT Technology (Suzhou) Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-09-26 |
| 5180-5240 MHz | Original Equipment | 2016-09-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-09-26 | PDF 1.9 MB |
| Internal Photos | Internal Photos | 2016-09-26 | PDF 1.3 MB |
| External Photos | External Photos | 2016-09-26 | PDF 399 KB |
| ID Label Location | ID Label/Location Info | 2016-09-26 | PDF 215.2 KB |
| Test Setup Photos | Test Setup Photos | 2016-09-26 | PDF 579.9 KB |
| Test Report | Test Report | 2016-09-26 | PDF 5.6 MB |
| Test Report | Test Report | 2016-09-26 | PDF 4.5 MB |
| Attestation Letter | Cover Letter(s) | 2016-09-26 | PDF 136.4 KB |
| Authorization Letter | Cover Letter(s) | 2016-09-26 | PDF 175.9 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-09-26 | PDF 199 KB |
| Cover Letter | Cover Letter(s) | 2016-09-26 | PDF 157.6 KB |
| RF Exposure | RF Exposure Info | 2016-09-26 | PDF 235.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 108.5 KB | |
| Schematics Metadata only | Schematics | PDF 951.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 571.5 KB |
Application Information
| Application ID | Hxw+KnFCdk/L7N/DKI4mPg== |
|---|---|
| Final Action Date | 2016-09-26 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023954829 |
| Model | GPT2541GNAC |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Equipo para acceso Fibra Optica |
| Responsible Party | Forest Xue, Engineer, Forest.Xue@mitrastar.cn , +86-510-8523-2888 |
| Agent | Robin Robin Robin, MRT, +86-512-66308358 |
| Test Firm | Wu Jian, MRT Technology (Suzhou) Co., Ltd, robinwu@mrt-cert.com  , 86-512-66308358 |
| TCB Email | c.schmidt@emcc.de  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is average conducted. Device is operating in a 2x2 Multiplexing MIMO configuration as described in this filing. This module is approved in mobile configurations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Hxw+KnFCdk/L7N/DKI4mPg== | 2016-09-26 | Original Equipment |
| 1Z6sA+ER58vyf+HP/B7yfw== | 2016-09-26 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application Hxw+KnFCdk/L7N/DKI4mPg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
EMCCons DR RASEK GmbH & Co. KG Stoernhofer Berg 15 Unterleinleiter, 91364 Germany |
Date of Grant: 09/26/2016 Application Dated: 09/26/2016 |
| Wuxi MitraStar Technology Co.,Ltd |
| 1-1# Minshan Road,Wuxi New Wu District |
| Jiangsu, China |
| Attention: Forest Xue , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC9MGPT2541GNAC |
| Name of Grantee: | Wuxi MitraStar Technology Co.,Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Equipo para acceso Fibra Optica |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.2032 |
| Output power listed is average conducted. Device is operating in a 2x2 Multiplexing MIMO configuration as described in this filing. This module is approved in mobile configurations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application Hxw+KnFCdk/L7N/DKI4mPg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Wuxi MitraStar Technology Co.,Ltd 1-1# Minshan Road,Wuxi New Wu District Jiangsu, China |
Date of Grant: 09/26/2016 Application Dated: 09/26/2016 |
| Attention: Forest Xue , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC9MGPT2541GNAC |
| Name of Grantee: | Wuxi MitraStar Technology Co.,Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Equipo para acceso Fibra Optica |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.2032 |
| Output power listed is average conducted. Device is operating in a 2x2 Multiplexing MIMO configuration as described in this filing. This module is approved in mobile configurations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
EMCCons DR RASEK GmbH & Co. KG Stoernhofer Berg 15 Unterleinleiter, 91364 Germany |
Date of Grant: 09/26/2016 Application Dated: 09/26/2016 |
| Wuxi MitraStar Technology Co.,Ltd |
| 1-1# Minshan Road,Wuxi New Wu District |
| Jiangsu, China |
| Attention: Forest Xue , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC9MGPT2541GNAC |
| Name of Grantee: | Wuxi MitraStar Technology Co.,Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Equipo para acceso Fibra Optica |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.4989 | ||
| 38 CC MO | 15E | 5190.0 - 5230.0 | 0.5598 |
| Output power listed is average conducted. Device is operating in a 4x4 MIMO configuration as described in this filing. This module is approved in mobile configurations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40 and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 1Z6sA+ER58vyf+HP/B7yfw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Wuxi MitraStar Technology Co.,Ltd 1-1# Minshan Road,Wuxi New Wu District Jiangsu, China |
Date of Grant: 09/26/2016 Application Dated: 09/26/2016 |
| Attention: Forest Xue , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AC9MGPT2541GNAC |
| Name of Grantee: | Wuxi MitraStar Technology Co.,Ltd |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Equipo para acceso Fibra Optica |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.4989 | ||
| 38 CC MO | 15E | 5190.0 - 5230.0 | 0.5598 |
| Output power listed is average conducted. Device is operating in a 4x4 MIMO configuration as described in this filing. This module is approved in mobile configurations. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40 and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
