RTBNL4 Range test device for verification... - FCC ID 2ACAH-RTBNL4

FCC ID 2ACAH-RTBNL4

Test Setup Photos

Range test device for verification of nEARlink 4 interface

by SBO Hearing A/S

Document preview loads when visible.

Document Details

FCC ID2ACAH-RTBNL4
Document ID3710269
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleTEST REPORT ANNEX
ApplicantSBO Hearing A/S
Equipment ClassRange test device for verification of nEARlink 4 interface
Product CodeRTBNL4
Application IDGxWt/sQqNn3k2gVtyc1JuQ==
Application PurposeOriginal Equipment
Application Date2018-01-11
Frequency Range3.84 MHz
FRN0016105751
Test FirmCTC advanced GmbH
Certified ByASMU Head of Regulatory Affairs
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-01-11
Available2018-01-11
Created2017-12-21
Modified2017-12-21
Pages6
File TypeAdobe Acrobat PDF
File Size709142
File SHA-2564fee445dfdcc76e7dc09abdce49fb9cd953b7089685c80d1a9f15797b599a7f9
PDF Metadata AuthorCetecom ICT Services GmbH
PDF Metadata ProducerCetecom ICT Services GmbH Microsoft® Word 2013
FCC.gov SourcesFCC.gov 3710269
