FCC ID 2ACCJB034
Test setup
LTE / UMTS / GSM Band Mobile Phone
Document preview loads when visible.
Document Details
| FCC ID | 2ACCJB034 |
|---|---|
| Document ID | 2801138 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | FCC RF Test Report |
| Applicant | TCL Communication Ltd. |
| Equipment Class | LTE / UMTS / GSM Band Mobile Phone |
| Product Code | B034 |
| Application ID | YL+FdhHBo6Rqf96jw/yQiQ== |
| Application Purpose | Original Equipment |
| Application Date | 2015-11-03 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0023603830 |
| Test Firm | SPORTON INTERNATIONAL (Shenzhen) INC. |
| Certified By | Michael Lin vice president |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 05/01/2016 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2015-11-03 |
| Available | 2016-05-01 |
| Created | 2015-10-30 |
| Modified | 2015-11-02 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 183277 |
| File SHA-256 | 836bd07c9bb292062c54dfadf962c6be00e08bceb7f5b6b591f54f35c7fcacf2 |
| PDF Metadata Author | WBU Documentation Depr. |
| PDF Metadata Producer | Microsoft® Word 2010 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 2801138 |
