B082 LTE/UMTS/GSM smart phone Teardown... - FCC ID 2ACCJB082

FCC ID 2ACCJB082

4055A Interior Photo

LTE/UMTS/GSM smart phone

by TCL Communication Ltd.

Document preview loads when visible.

Document Details

FCC ID2ACCJB082
Document ID3243979
Document TypeInternal Photos
Description4055A Interior Photo
Document Title4055A Interior Photo
ApplicantTCL Communication Ltd.
Equipment ClassLTE/UMTS/GSM smart phone
Product CodeB082
Application IDrJMz3sBQkgvnw78ak/Oq/g==
Application PurposeOriginal Equipment
Application Date2017-01-06
FRN0023603830
Test FirmTelecommunication Technology Labs,
Certified ByLi Bo Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-12-30
Available2017-01-06
Created2016-12-21
Modified2016-12-21
Pages4
File TypeAdobe Acrobat PDF
File Size775192
File SHA-256d0d737bc329caaa42b1b70570c8c0c4124efc403e27d9b3450412a4c5285eebd
PDF Metadata Authoryang
PDF Metadata Produceryang Acrobat Distiller 10.0.0 (Windows)
