B119 Wifi Router External Photos - FCC ID 2ACCJB119
FCC ID 2ACCJB119
external photo
Wifi Router
Document preview loads when visible.
Document Details
| FCC ID | 2ACCJB119 |
|---|---|
| Document ID | 4667151 |
| Document Type | External Photos |
| Description | external photo |
| Applicant | TCL Communication Ltd. |
| Equipment Class | Wifi Router |
| Product Code | B119 |
| Application ID | aECgAlAGQrWEGdlMBuYZQQ== |
| Application Purpose | Original Equipment |
| Application Date | 2020-03-31 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0023603830 |
| Test Firm | Shenzhen Academy of Information and Communications |
| Certified By | Gong Zhizhou Product Certification Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 09/27/2020 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2020-03-27 |
| Available | 2020-09-27 |
| Created | 2020-03-16 |
| Modified | 2020-03-16 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 1529116 |
| File SHA-256 | f7a435b5f20f3b0079986e80fe9476d67ef55fc85be84a7e010f79d5f8833571 |
| PDF Metadata Author | wang carol |
| PDF Metadata Producer | Microsoft® Word 适用于 Office 365 wang carol |
| FCC.gov Sources | FCC.gov 4667151, FCC.gov 4667133, FCC.gov 4666447 |
