B128 TIMEX FamilyConnect SENIOR Test Setup Photos - FCC ID 2ACCJB128

FCC ID 2ACCJB128

DTS Test Setup Photos

TIMEX FamilyConnect SENIOR

by TCL Communication Ltd.

Document preview loads when visible.

Document Details

FCC ID2ACCJB128
Document ID5312329
Document TypeTest Setup Photos
DescriptionDTS Test Setup Photos
ApplicantTCL Communication Ltd.
Equipment ClassTIMEX FamilyConnect SENIOR
Product CodeB128
Application ID832eWJcNL0CokemzRtTwmw==
Application PurposeOriginal Equipment
Application Date2021-06-27
Frequency Range2402-2480 MHz
FRN0023603830
Test FirmShenzhen Academy of Metrology and Quality Inspec
Certified ByFangai Zhou
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/25/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-06-27
Available2021-12-25
Created2021-06-15
Modified2021-06-15
Pages4
File TypeAdobe Acrobat PDF
File Size1407497
File SHA-256b13657e91afa3efcd0c2b9dce1cf6d8028916885b88735ea1f2a2e5f8dfc09a3
PDF Metadata Authoryckj
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 5312329
