FCC ID 2ACCJBC01
Home Bridge
by TCL Communication Ltd.
Grantee Code: 2ACCJ Product Code: BC01
Latest application date: 2017-02-07
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2480 MHz | Original Equipment | 2017-02-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| LIFECONNECT QG US CJB1H1002AAA v0.1-170116_rev1 | Users Manual | 2017-02-07 | PDF 622.5 KB |
| HB01 Interior Photos_rev1 | Internal Photos | 2017-02-07 | PDF 580.4 KB |
| HB01 external photos | External Photos | 2017-02-07 | PDF 758.9 KB |
| label_rev2 | ID Label/Location Info | 2017-02-07 | PDF 209.2 KB |
| test_setup_photo_rev1 | Test Setup Photos | 2017-02-07 | PDF 645.5 KB |
| I16Z42400-SRD01_FCC Report_WLAN 2.4G-Rev0_part1 | Test Report | 2017-02-07 | PDF 5.4 MB |
| I16Z42400-SRD01_FCC Report_WLAN 2.4G-Rev0_part2 | Test Report | 2017-02-07 | PDF 5.5 MB |
| I16Z42400-SRD01_FCC Report_WLAN 2.4G-Rev0_part3 | Test Report | 2017-02-07 | PDF 5.1 MB |
| I16Z42400-SRD02-FCCReport_ZigBee_2.4G_Rev0 | Test Report | 2017-02-07 | PDF 4.1 MB |
| HB01 Agent Letter | Cover Letter(s) | 2017-02-07 | PDF 183.6 KB |
| HB01_FCC Confidentiality Letter | Cover Letter(s) | 2017-02-07 | PDF 258.9 KB |
| I16Z42400-SEM01_MPE_Rev1 | RF Exposure Info | 2017-02-07 | PDF 179.4 KB |
| Confidential_Block diagram-HB01_rev1 Metadata only | Block Diagram | PDF 115.9 KB | |
| Confidential_HB01_LIFECONNECT_Schematics Metadata only | Schematics | PDF 2.8 MB | |
| Confidential_HB01 Operation Description_ Metadata only | Operational Description | PDF 292.4 KB | |
| Confidential_HB01_Antenna Details Metadata only | Operational Description | PDF 58.7 KB | |
| Confidential_HB01 Tune up Procedure Metadata only | Parts List/Tune Up Info | PDF 98.6 KB | |
| Confidential_HB01__eBOM V4_SBA1H100000C_20160918 Metadata only | Parts List/Tune Up Info | PDF 197.1 KB |
Application Information
| Application ID | nA/p3BSHHGBfJjQgAzy9Qg== |
|---|---|
| Final Action Date | 2017-02-07 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023603830 |
| Model | BC01 |
| Frequency Range | 2405-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Home Bridge |
| Responsible Party | Zhizhou Gong, zhizhou.gong@tcl.com  , +8675536611722 |
| Technical Contact | Xue Zhen, CTTL-Terminals Test Lab of China Academy of Teleco, xuezhen@catr.cn  , 86-10-62304633 |
| Test Firm | zhen xue, Telecommunication Technology Labs,, xuezhen@catr.cn , 861062304633 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output is conducted. The device is an 802.11n device in a 2x2 Spatial Multiplexing MIMO configuration as described in this filing. The device has been certified for mobile use and any co-location must be done through the use of FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz Bandwidth. |
