H039 HSUPA/HSDPA/UMTS Tri-band/GSM Quad-band... - FCC ID 2ACCJH039

FCC ID 2ACCJH039

4017A Interior Photo

HSUPA/HSDPA/UMTS Tri-band/GSM Quad-band mobile phone

by TCL Communication Ltd.

Document preview loads when visible.

Document Details

FCC ID2ACCJH039
Document ID2891576
Document TypeInternal Photos
Description4017A Interior Photo
Document Title4017A Interior Photo
ApplicantTCL Communication Ltd.
Equipment ClassHSUPA/HSDPA/UMTS Tri-band/GSM Quad-band mobile phone
Product CodeH039
Application ID9wOXAX0pfTiS4tJnSNmhEA==
Application PurposeOriginal Equipment
Application Date2016-02-01
Frequency Range1850.2-1909.8 MHz
FRN0023603830
Test FirmTelecommunication Technology Labs,
Certified ByLi Bo Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-02-01
Available2016-02-01
Created2016-01-22
Modified2016-01-22
Pages3
File TypeAdobe Acrobat PDF
File Size329728
File SHA-2568f25a4fcbc5c595c3f61e45f6edcda96d0e96ba02c43d04976057ccc5257da26
PDF Metadata Authoryang
PDF Metadata Produceryang Acrobat Distiller 10.0.0 (Windows)
