MRR20 Automotive Radar Teardown Internal... - FCC ID 2ACDX-MRR-20
FCC ID 2ACDX-MRR-20
Internal Photos
Automotive Radar
by MANDO corp.
Document preview loads when visible.
Document Details
| FCC ID | 2ACDX-MRR-20 |
|---|---|
| Document ID | 5288728 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Internal Photos |
| Applicant | MANDO corp. |
| Equipment Class | Automotive Radar |
| Product Code | MRR20 |
| Application ID | d8FkatpeQ4FRte7sjT5S9A== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2021-06-11 |
| Frequency Range | 76500 MHz |
| FRN | 0023615339 |
| Test Firm | KOSTEC Co., Ltd |
| Certified By | Suhan Kim Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 12/08/2021 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2021-06-11 |
| Available | 2021-12-08 |
| Created | 2021-06-07 |
| Modified | 2021-06-09 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 678152 |
| File SHA-256 | 4d3be7618f74b93b8d8618d94420b01a404ca8b6be56314c144b3fc8f72d5a38 |
| PDF Metadata Author | suhyun.seo[서수현] |
| PDF Metadata Producer | Microsoft® Word Office 365용 suhyun.seo[서수현] |
| FCC.gov Sources | FCC.gov 5288728 |
