FCC ID 2ACDZ-WT1HB12
WT1HB12
by Hangzhou Gubei Electronics Technology Co.,Ltd
Grantee Code: 2ACDZ Product Code: WT1HB12
Latest application date: 2017-03-03
Device Images
FCC ID Device Details
| FCC ID | 2ACDZ-WT1HB12 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACDZ |
| Product Code | WT1HB12 |
| Applicant Business | Hangzhou Gubei Electronics Technology Co.,Ltd 🇨🇳 |
| Related Domains |  broadlink.com.cn |
| Equipment Class | WT1HB12 |
| Test Firm | Intertek Testing Services Limited Shanghai |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-03-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual_1 | Users Manual | 2017-03-03 | PDF 488.2 KB |
| Internal picture | Internal Photos | 2017-03-03 | PDF 159.2 KB |
| External picture | External Photos | 2017-03-03 | PDF 352.3 KB |
| Label&location | ID Label/Location Info | 2017-03-03 | PDF 479 KB |
| Test Setup | Test Setup Photos | 2017-03-03 | PDF 208.1 KB |
| Test report_1 | Test Report | 2017-03-03 | PDF 3.2 MB |
| Confidentiality | Cover Letter(s) | 2017-03-03 | PDF 563.5 KB |
| FCC Agency | Cover Letter(s) | 2017-03-03 | PDF 282.2 KB |
| Modular Approval_FCC | Cover Letter(s) | 2017-03-03 | PDF 845.1 KB |
| Product Declaration | Cover Letter(s) | 2017-03-03 | PDF 47.8 KB |
| FCC MPE | RF Exposure Info | 2017-03-03 | PDF 70 KB |
| Confidential_Block Diagram_1 Metadata only | Block Diagram | PDF 108.3 KB | |
| Confidential_Schematics_1 Metadata only | Schematics | PDF 217.9 KB | |
| Confidential_Operation Discription Metadata only | Operational Description | PDF 13.2 KB | |
| Datasheet-MT7681 Metadata only | Operational Description | PDF 336.4 KB |
Application Information
| Application ID | 0PL7foyciLlBj8h4om7jtA== |
|---|---|
| Final Action Date | 2017-03-03 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023611767 |
| Model | WT1HB12 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WT1HB12 |
| Responsible Party | Nancy Shao, nancy@broadlink.com.cn , 0571-86691817 |
| Technical Contact | Wade Zhang, Intertek Testing Services Limited Shanghai, wakeyou.wang@intertek.com  , 86-21-61278448 |
| Test Firm | Jonny Jing, Intertek Testing Services Limited Shanghai, jonny.jing@intertek.com , 86-21-61278271 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is Conducted. Modular Approval. This device is granted for use in Mobile only configurations in which the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0PL7foyciLlBj8h4om7jtA== | 2017-03-03 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0870000 | 15C |
Grants
TCB Grant - Application 0PL7foyciLlBj8h4om7jtA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 03/03/2017 Application Dated: 03/01/2017 |
| Hangzhou Gubei Electronics Technology Co.,Ltd |
| Room106, Building 1, No.611 Jianghong Road, |
| Binjiang, Hangzhou, Zhejiang 310052 P.R. China |
| Hangzhou, China |
| Attention: Nancy Shao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACDZ-WT1HB12 |
| Name of Grantee: | Hangzhou Gubei Electronics Technology Co.,Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | WT1HB12 |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.087 |
| Power Output listed is Conducted. Modular Approval. This device is granted for use in Mobile only configurations in which the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application 0PL7foyciLlBj8h4om7jtA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Hangzhou Gubei Electronics Technology Co.,Ltd Room106, Building 1, No.611 Jianghong Road, Binjiang, Hangzhou, Zhejiang 310052 P.R. China Hangzhou, China |
Date of Grant: 03/03/2017 Application Dated: 03/01/2017 |
| Attention: Nancy Shao |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACDZ-WT1HB12 |
| Name of Grantee: | Hangzhou Gubei Electronics Technology Co.,Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | WT1HB12 |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.087 |
| Power Output listed is Conducted. Modular Approval. This device is granted for use in Mobile only configurations in which the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
