FCC ID 2ACFB-G9
SMART TV BOX
by Shenzhen Shiningworth Technology Co., Ltd.
Grantee Code: 2ACFB Product Code: G9
Latest application date: 2016-07-21
Device Images
FCC ID Device Details
| FCC ID | 2ACFB-G9 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACFB |
| Product Code | G9 |
| Applicant Business | Shenzhen Shiningworth Technology Co., Ltd. 🇨🇳 |
| Related Domains |  tvpcbox.com |
| Equipment Class | SMART TV BOX |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-07-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-21 | PDF 613.6 KB |
| Internal photos | Internal Photos | 2016-07-21 | PDF 835.4 KB |
| External photos | External Photos | 2016-07-21 | PDF 646 KB |
| Label | ID Label/Location Info | 2016-07-21 | PDF 35 KB |
| Label location | ID Label/Location Info | 2016-07-21 | PDF 123.3 KB |
| RF Test Set-up Photos | Test Setup Photos | 2016-07-21 | PDF 268.2 KB |
| RF Test Report | Test Report | 2016-07-21 | PDF 4.8 MB |
| DOC Attestation Letter | Attestation Statements | 2016-07-21 | PDF 61.9 KB |
| Authorization letter | Cover Letter(s) | 2016-07-21 | PDF 24 KB |
| DTS Ch12&13 Declaration letter | Cover Letter(s) | 2016-07-21 | PDF 99.7 KB |
| Family model letter | Cover Letter(s) | 2016-07-21 | PDF 49 KB |
| LTC Letter | Cover Letter(s) | 2016-07-21 | PDF 94.2 KB |
| MPE Report | RF Exposure Info | 2016-07-21 | PDF 13.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 46.9 KB | |
| Schematics Metadata only | Schematics | PDF 404.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 72 KB |
Application Information
| Application ID | vRv4LY0IKUY71TEy+2Xc4w== |
|---|---|
| Final Action Date | 2016-07-21 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023638992 |
| Model | G9 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | SMART TV BOX |
| Responsible Party | Sam Kwok, Hardware Manager, sam@tvpcbox.com , 0755-29172839 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device contains 20 and 40 MHz signal bandwidth. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| vRv4LY0IKUY71TEy+2Xc4w== | 2016-07-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0330000 | 15C |
Grants
TCB Grant - Application vRv4LY0IKUY71TEy+2Xc4w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 07/21/2016 Application Dated: 07/21/2016 |
| Shenzhen Shiningworth Technology Co., Ltd. |
| Room 610-613, Block B, Huameiju Business Center, |
| Xinhu Road, Baoan District, |
| Shenzhen, Guangdong, China |
| Attention: Sam Kwok , Hardware Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACFB-G9 |
| Name of Grantee: | Shenzhen Shiningworth Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | SMART TV BOX |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.033 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device contains 20 and 40 MHz signal bandwidth. |
EAS Grant - Application vRv4LY0IKUY71TEy+2Xc4w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen Shiningworth Technology Co., Ltd. Room 610-613, Block B, Huameiju Business Center, Xinhu Road, Baoan District, Shenzhen, Guangdong, China |
Date of Grant: 07/21/2016 Application Dated: 07/21/2016 |
| Attention: Sam Kwok , Hardware Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACFB-G9 |
| Name of Grantee: | Shenzhen Shiningworth Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | SMART TV BOX |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.033 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Device contains 20 and 40 MHz signal bandwidth. |
