X410 Mobile Phone Test Setup Photos - FCC ID 2ACLMX410
FCC ID 2ACLMX410
Test setup photo
Mobile Phone
Document preview loads when visible.
Document Details
| FCC ID | 2ACLMX410 |
|---|---|
| Document ID | 2871948 |
| Document Type | Test Setup Photos |
| Description | Test setup photo |
| Document Title | 15071088-FCC-R3 WIFI 11CH |
| Applicant | Social Mobile Telecommunications |
| Equipment Class | Mobile Phone |
| Product Code | X410 |
| Application ID | hs2peu1MR4Jj/iAQmKJuAQ== |
| Application Purpose | Original Equipment |
| Application Date | 2016-01-14 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0023721392 |
| Test Firm | SIEMIC (Shenzhen-China) Laboratories |
| Certified By | Freddy Morcos |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-01-13 |
| Available | 2016-01-14 |
| Created | 2017-08-25 |
| Modified | 2017-08-25 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 226465 |
| File SHA-256 | 7a622b1156dd445a1b72422ff814101b0b2f0b0da46365dc21d9b8077509bcb5 |
| PDF Metadata Author | Administrator |
| PDF Metadata Creator | PScript5.dll Version 5.2.2 |
| PDF Metadata Producer | GPL Ghostscript 9.18 |
| FCC.gov Sources | FCC.gov 2871948, FCC.gov 2871949 |
