FL5845 Wireless Transmitter System Label... - FCC ID 2ACLSFL58-45
FCC ID 2ACLSFL58-45
Labels
Wireless Transmitter System
by EBlink
Document preview loads when visible.
Document Details
| FCC ID | 2ACLSFL58-45 |
|---|---|
| Document ID | 3044968 |
| Document Type | ID Label/Location Info |
| Description | Labels |
| Applicant | EBlink |
| Equipment Class | Wireless Transmitter System |
| Product Code | FL5845 |
| Application ID | zdFkjd7QCKavvefux8mvaQ== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2016-06-29 |
| Frequency Range | 5725-5850 MHz |
| FRN | 0021750112 |
| Test Firm | LCIE |
| Certified By | Jerome Sottas |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-06-29 |
| Available | 2016-06-29 |
| Created | 2016-06-09 |
| Modified | 2016-06-09 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 206035 |
| File SHA-256 | d9ff1acdaff0c24dcf696da55f7a65a90ece41f6dd2fb07207f0ae18f05a99c2 |
| PDF Metadata Author | Jerome Sottas |
| PDF Metadata Producer | Microsoft® Word 2010 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 3044968 |
