FCC ID 2ACMYAWF61
1080p Outdoor Wireless Network Camera
by Atoms Labs LLC
Grantee Code: 2ACMY Product Code: AWF61
Latest application date: 2016-01-27
Device Images
FCC ID Device Details
| FCC ID | 2ACMYAWF61 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACMY |
| Product Code | AWF61 |
| Applicant Business | Atoms Labs LLC 🇺🇸 |
| Related Domains |  atomslabs.com |
| Equipment Class | 1080p Outdoor Wireless Network Camera |
| Test Firm | Dongguan Dongdian Testing Service Co.,Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-01-27 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-01-27 | PDF 686.5 KB |
| Internal photos | Internal Photos | 2016-01-27 | PDF 1.1 MB |
| External photos | External Photos | 2016-01-27 | PDF 792.9 KB |
| Label | ID Label/Location Info | 2016-01-27 | PDF 131.3 KB |
| Test setup | Test Setup Photos | 2016-01-27 | PDF 225.4 KB |
| Test report | Test Report | 2016-01-27 | PDF 3.3 MB |
| Cover letter | Cover Letter(s) | 2016-01-27 | PDF 352.2 KB |
| RF Exposure | RF Exposure Info | 2016-01-27 | PDF 72.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 42.7 KB | |
| Schematics Metadata only | Schematics | PDF 176.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 73.8 KB |
Application Information
| Application ID | GF6rgVEdT/RVkJ0sc+IAHw== |
|---|---|
| Final Action Date | 2016-01-27 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023667025 |
| Model | AWF61 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 1080p Outdoor Wireless Network Camera |
| Responsible Party | Justin Wang, justin.wang@atomslabs.com , 3105989211 |
| Test Firm | Jamy Yu, Dongguan Dongdian Testing Service Co.,Ltd, yqaly@163.com  , 086-0769-22891499 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| GF6rgVEdT/RVkJ0sc+IAHw== | 2016-01-27 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0610940 | 15C |
Grants
TCB Grant - Application GF6rgVEdT/RVkJ0sc+IAHw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 01/27/2016 Application Dated: 01/27/2016 |
| Atoms Labs LLC |
| 2670 Firewheel Dr. Suite D |
| Flower Mound, TX 75028 |
| Attention: Justin Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACMYAWF61 |
| Name of Grantee: | Atoms Labs LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | 1080p Outdoor Wireless Network Camera |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.061094 |
| Power listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application GF6rgVEdT/RVkJ0sc+IAHw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Atoms Labs LLC 2670 Firewheel Dr. Suite D Flower Mound, TX 75028 United States |
Date of Grant: 01/27/2016 Application Dated: 01/27/2016 |
| Attention: Justin Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACMYAWF61 |
| Name of Grantee: | Atoms Labs LLC |
| Equipment Class: | Digital Transmission System |
| Notes: | 1080p Outdoor Wireless Network Camera |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.061094 |
| Power listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| Mail To: |
