FCC ID 2ACMYAWS31R

FCC ID 2ACMYAWS31R External-Photos, 2ACMY AWS31R, 2ACMYAWS31R, 2ACMYAWS3IR, 2ACMYAW531R

Atoms Labs LLC 7 inch LCD Real-Time Digital Wireless Monitor AWS31R

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: 2ACMYAWS31R is 2ACMY. The remaining characters of the FCC ID, AWS31R, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: 7 inch LCD Real-Time Digital Wireless Monitor

*Please Check Individual Documents for more images

Application: 7 inch LCD Real-Time Digital Wireless Monitor
Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Short Link: fcc.id/2ACMYAWS31R
Sources: FCC.gov | FCC.report
Registered By: Atoms Labs LLC - 2ACMY (United States)

App #	Purpose	Date	Unique ID
1	Original Equipment	2016-03-02	zaRNTjQHr8zRZcU8Q9EQwQ==

Operating Frequencies

Frequency Range	Power Output	Rule Parts	Line Entry
2.41425-2.4615 GHz	53.46 mW	15C	1

Exhibits

Document	Type	Submitted Available
User manual	Users Manual Adobe Acrobat PDF (1504 kB)	2016-03-02 2016-03-02
Cover letter	Cover Letter(s) Adobe Acrobat PDF (352 kB)	2016-03-02 2016-03-02
Test setup	Test Setup Photos Adobe Acrobat PDF (207 kB)	2016-03-02 2016-03-02
Test report	Test Report Adobe Acrobat PDF (1946 kB)	2016-03-02 2016-03-02
RF Exposure	RF Exposure Info Adobe Acrobat PDF (57 kB)	2016-03-02 2016-03-02
Internal photos	Internal Photos Adobe Acrobat PDF (372 kB)	2016-03-02 2016-03-02
Label	ID Label/Location Info Adobe Acrobat PDF (203 kB)	2016-03-02 2016-03-02
External photos	External Photos Adobe Acrobat PDF (784 kB)	2016-03-02 2016-03-02
Operational Description	Operational Description Adobe Acrobat PDF (24 kB)	2016-03-02
Schematics	Schematics Adobe Acrobat PDF (321 kB)	2016-03-02
Block Diagram	Block Diagram Adobe Acrobat PDF (100 kB)	2016-03-02

Application Forms

1 (2016-03-02)

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	Atoms Labs LLC
FCC Registration Number (FRN):	0023667025
Alphanumeric FCC ID:	2ACMYAWS31R
Unique Application Identifier:	zaRNTjQHr8zRZcU8Q9EQwQ==
Line one:	2670 Firewheel Dr. Suite D
City:	Flower Mound
State:	Texas
Country:	United States
Zip Code:	75028

TCB Information

TCB Application Email Address:	stuart.beck@nemko.com
TCB Scope:	A4: UNII devices & low power transmitters using spread spectrum techniques

FCC ID

Grantee Code:	2ACMY
Product Code:	AWS31R

Person at the applicant's address to receive grant or for contact

Name:

Daniel Steffy

Telephone Number:

3105989211

Extension:

Fax Number:	8447678544
Email:	justin.wang@atomslabs.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: No

If so, specify the short-term confidentiality release date (MM/DD/YYYY format):
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	7 inch LCD Real-Time Digital Wireless Monitor

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? No

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Dongguan Dongdian Testing Service Co.,Ltd

First Name: Jamy

Last Name: Yu

Telephone Number:

086-0769-22891499

Extension:

8151

E-mail: yqaly@163.com

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Power output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503).

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes.

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements.

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time.

Signature of Authorized Person Filing: Kevin Feng

Title of authorized signature: Manager

Applications are submitted for FCC ID and Grant requests. Click an above application to view details

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Nemko Canada Inc.
303 River Road
Ottawa, Ontario, K1V 1H2
Canada

Date of Grant: 03/02/2016

Application Dated: 03/02/2016

Atoms Labs LLC

2670 Firewheel Dr. Suite D

Flower Mound, TX 75028

Attention: Daniel Steffy

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ACMYAWS31R

Name of Grantee:	Atoms Labs LLC

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	7 inch LCD Real-Time Digital Wireless Monitor

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
	15C	2414.25 - 2461.5	0.05346

Power output listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

Atoms Labs LLC
2670 Firewheel Dr. Suite D
Flower Mound, TX 75028
United States
