HW706V Heart rate armband Test Setup Photos - FCC ID 2ACN7-HW706V

FCC ID 2ACN7-HW706V

test setup photos

Heart rate armband

by Shenzhen Fitcare Electronics Co., Ltd

Document preview loads when visible.

Document Details

FCC ID2ACN7-HW706V
Document ID4185940
Document TypeTest Setup Photos
Descriptiontest setup photos
Document TitleANNEX_Part 15C
ApplicantShenzhen Fitcare Electronics Co., Ltd
Equipment ClassHeart rate armband
Product CodeHW706V
Application IDoRy6CRadLSBBPVhZx0zHCA==
Application PurposeOriginal Equipment
Application Date2019-03-01
Frequency Range2402-2480 MHz
FRN0023753544
Test FirmWaltek Testing Group (Shenzhen) Co., Ltd.
Certified ByJandy So PSQ Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2019-03-01
Available2019-03-01
Created2019-02-28
Modified2019-02-28
Pages3
File TypeAdobe Acrobat PDF
File Size348504
File SHA-2569424f3e0c044f18b61b7cae61a0bcefb3ecbf8a8438e6dcc9b1b07d89f4a46d3
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAdministrator Acrobat Distiller 9.3.2 (Windows)
FCC.gov SourcesFCC.gov 4185940, FCC.gov 4185953
