FCC ID 2ACOE-SKW71
WIFI module
by Skylab M&C; Technology Co.,Ltd.
Grantee Code: 2ACOE Product Code: SKW71
Latest application date: 2015-10-30
Device Images
FCC ID Device Details
| FCC ID | 2ACOE-SKW71 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACOE |
| Product Code | SKW71 |
| Applicant Business | Skylab M&C; Technology Co.,Ltd. 🇨🇳 |
| Related Domains |  skylab.com.cn |
| Equipment Class | WIFI module |
| Test Firm | ATT Product Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-10-30 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2015-10-30 | PDF 666 KB |
| Internal photos | Internal Photos | 2015-10-30 | PDF 1.9 MB |
| External photos | External Photos | 2015-10-30 | PDF 1.9 MB |
| Label | ID Label/Location Info | 2015-10-30 | PDF 782.7 KB |
| Test setup | Test Setup Photos | 2015-10-30 | PDF 911.9 KB |
| Test report | Test Report | 2015-10-30 | PDF 2.9 MB |
| Cover letter | Cover Letter(s) | 2015-10-30 | PDF 314.5 KB |
| RF Exposure | RF Exposure Info | 2015-10-30 | PDF 70.9 KB |
| Block Diagram Metadata only | Block Diagram | PDF 32.5 KB | |
| Schematics Metadata only | Schematics | PDF 51.8 KB | |
| Operational Description Metadata only | Operational Description | PDF 20 KB |
Application Information
| Application ID | So0Ex53DQObO4x0fM75Kpw== |
|---|---|
| Final Action Date | 2015-10-30 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023759574 |
| Model | SKW71 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WIFI module |
| Responsible Party | Sam Chen, manager, sam.chen@skylab.com.cn , 0755-83408210 |
| Test Firm | Dick Lian, ATT Product Service Co., Ltd., dick@attps.cn  , 86076985098000 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| So0Ex53DQObO4x0fM75Kpw== | 2015-10-30 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0598400 | 15C |
Grants
TCB Grant - Application So0Ex53DQObO4x0fM75Kpw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 10/30/2015 Application Dated: 10/30/2015 |
| Skylab M&C Technology Co.,Ltd. |
| 6/F,Building 9,Lijincheng park, |
| Gongye East Rd,Longhua St,Longhua District, |
| Shenzhen, 518109 China |
| Attention: Sam Chen , manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACOE-SKW71 |
| Name of Grantee: | Skylab M&C Technology Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WIFI module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.05984 |
| Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
EAS Grant - Application So0Ex53DQObO4x0fM75Kpw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Skylab M&C Technology Co.,Ltd. 6/F,Building 9,Lijincheng park, Gongye East Rd,Longhua St,Longhua District, Shenzhen, 518109 China |
Date of Grant: 10/30/2015 Application Dated: 10/30/2015 |
| Attention: Sam Chen , manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACOE-SKW71 |
| Name of Grantee: | Skylab M&C Technology Co.,Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WIFI module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.05984 |
| Limited Single Modular Approval. Power output listed is conducted. This device has a 20 MHz and 40 MHz bandwidth mode. Approval is limited to OEM installation only. Compliance of this device in all final host configurations is the responsibility of the Grantee. This device is to be used only for mobile and fixed applications. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other transmitter. OEM integrators must be provided with antenna installation instructions and labeling requirements for finished products. OEM integrators and End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. This grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. Separate approval is required for all other operating configurations, including portable configurations with respect to 2.1093 and different antenna configurations. |
