BT950 Bluetooth Headset Test Setup Photos - FCC ID 2ACP4BT950

FCC ID 2ACP4BT950

Test setup photos

Bluetooth Headset

by Sentry Industries limited

Document preview loads when visible.

Document Details

FCC ID2ACP4BT950
Document ID3076470
Document TypeTest Setup Photos
DescriptionTest setup photos
ApplicantSentry Industries limited
Equipment ClassBluetooth Headset
Product CodeBT950
Application IDUNA+xte3xFj4qXrwKLJvxQ==
Application PurposeOriginal Equipment
Application Date2016-07-26
Frequency Range2402-2480 MHz
FRN0023775950
Test FirmDongguan Precise Testing Service Co., Ltd.
Certified ByPeetu Melwani
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-07-26
Available2016-07-26
Created2016-07-25
Modified2016-07-25
Pages1
File TypeAdobe Acrobat PDF
File Size152990
File SHA-256ff6011f1d8bede69ccea00ea65345493e14cc19b34f4f5dda2f234678f855792
PDF Metadata AuthorUSER
PDF Metadata ProducerMicrosoft Office Word 2007 Microsoft Office Word 2007
FCC.gov SourcesFCC.gov 3076470
