FCC ID 2ACRL2DF
Audio infotainment unit
by Harman Automotive Electronic Systems (Suzhou) Co., Ltd
Grantee Code: 2ACRL Product Code: 2DF
Latest application date: 2017-01-09
Device Images
FCC ID Device Details
| FCC ID | 2ACRL2DF |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACRL |
| Product Code | 2DF |
| Applicant Business | Harman Automotive Electronic Systems (Suzhou) Co., Ltd 🇨🇳 |
| Related Domains |  harman.com |
| Equipment Class | Audio infotainment unit |
| Test Firm | Shenzhen CTL Testing Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-01-09 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 10 user manual part 1 | Users Manual | 2017-01-09 | PDF 4.3 MB |
| 10 user manual part 2 | Users Manual | 2017-01-09 | PDF 1.8 MB |
| 03 internal photos | Internal Photos | 2017-01-09 | PDF 3.6 MB |
| 02 external photos | External Photos | 2017-01-09 | PDF 347.1 KB |
| 04 label and label location | ID Label/Location Info | 2017-01-09 | PDF 360.9 KB |
| 09 test setup photos | Test Setup Photos | 2017-01-09 | PDF 295.7 KB |
| 08 Test report | Test Report | 2017-01-09 | PDF 3.6 MB |
| 11 confidentiality request letter(permanent) v2 0 | Cover Letter(s) | 2017-01-09 | PDF 14.7 KB |
| RF Exposure Info_FCC | RF Exposure Info | 2017-01-09 | PDF 435.2 KB |
| 01 block diagram Metadata only | Block Diagram | PDF 649.1 KB | |
| 06 schematic Metadata only | Schematics | PDF 1.8 MB | |
| 05 operation description Metadata only | Operational Description | PDF 195.5 KB |
Application Information
| Application ID | ECaCcMg0OLKwxeYvxWvt2A== |
|---|---|
| Final Action Date | 2017-01-09 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023792583 |
| Model | 2DF |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Audio infotainment unit |
| Responsible Party | danie hong, Regulatory Compliance Engineer, danie.hong@harman.com , +86 512 62554740 |
| Test Firm | Tracy Qi, Shenzhen CTL Testing Technology Co., Ltd., qihui@ctl-lab.com  , 86-755-89486194 |
| TCB Email | TCB@cetecom.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is peak conducted |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ECaCcMg0OLKwxeYvxWvt2A== | 2017-01-09 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0022000 | 15C |
Grants
TCB Grant - Application ECaCcMg0OLKwxeYvxWvt2A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CTC advanced GmbH Untertuerkheimer Strasse 6-10 66117 Saarbruecken, Germany |
Date of Grant: 01/09/2017 Application Dated: 01/09/2017 |
| Harman Automotive Electronic Systems (Suzhou) Co., Ltd |
| No125 Fangzhou Rd, Suzhou SIP, Jiangsu, China |
| Suzhou SIP, 215024 China |
| Attention: danie hong , Regulatory Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACRL2DF |
| Name of Grantee: | Harman Automotive Electronic Systems (Suzhou) Co., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Audio infotainment unit |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 |
| Output power listed is peak conducted |
EAS Grant - Application ECaCcMg0OLKwxeYvxWvt2A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Harman Automotive Electronic Systems (Suzhou) Co., Ltd No125 Fangzhou Rd, Suzhou SIP, Jiangsu, China Suzhou SIP, 215024 China |
Date of Grant: 01/09/2017 Application Dated: 01/09/2017 |
| Attention: danie hong , Regulatory Compliance Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACRL2DF |
| Name of Grantee: | Harman Automotive Electronic Systems (Suzhou) Co., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Audio infotainment unit |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0022 |
| Output power listed is peak conducted |
