FCC ID 2ACS612TX
Controller of Flip Flop Drone
by ZEGO ELECTRONIC COMPANY LIMITED
Grantee Code: 2ACS6 Product Code: 12TX
Latest application date: 2016-07-11
Device Images
FCC ID Device Details
| FCC ID | 2ACS612TX |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACS6 |
| Product Code | 12TX |
| Applicant Business | ZEGO ELECTRONIC COMPANY LIMITED |
| Related Domains |  yrtoys.com |
| Equipment Class | Controller of Flip Flop Drone |
| Test Firm | CMA Industrial Development Foundation Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2475 MHz | Original Equipment | 2016-07-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-07-11 | PDF 1.9 MB |
| Internal Photos | Internal Photos | 2016-07-11 | PDF 677.3 KB |
| External Photos | External Photos | 2016-07-11 | PDF 222.5 KB |
| Label Sample | ID Label/Location Info | 2016-07-11 | PDF 110.6 KB |
| Test Setup Photos | Test Setup Photos | 2016-07-11 | PDF 649.7 KB |
| Test Report | Test Report | 2016-07-11 | PDF 992.7 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-07-11 | PDF 966 KB |
| POA | Cover Letter(s) | 2016-07-11 | PDF 953.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 32.6 KB | |
| PCB Schematic Metadata only | Schematics | PDF 343.3 KB | |
| Schematics Metadata only | Schematics | PDF 617.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 4.4 KB |
Application Information
| Application ID | Zrbww7Fs3Oh5CWL6YgtEOg== |
|---|---|
| Final Action Date | 2016-07-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023807795 |
| Model | 12TX |
| Frequency Range | 2402-2475 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Controller of Flip Flop Drone |
| Responsible Party | JADE WANG, VICE-GENERAL MANAGER, jadewang@yrtoys.com , (86) 755-27062168 |
| Test Firm | Joey Kwok, CMA Industrial Development Foundation Limited, joeykwok@cmatesting.org  , +852 2690 8255 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Zrbww7Fs3Oh5CWL6YgtEOg== | 2016-07-11 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2402-2475 MHz | 15C |
Grants
TCB Grant - Application Zrbww7Fs3Oh5CWL6YgtEOg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 07/11/2016 Application Dated: 07/11/2016 |
| ZEGO ELECTRONIC COMPANY LIMITED |
| ROOM 703, KOWLOON BUILDING, |
| 555 NATHAN ROAD, |
| KOWLOON, Hong Kong |
| Attention: JADE WANG , VICE-GENERAL MANAGER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACS612TX |
| Name of Grantee: | ZEGO ELECTRONIC COMPANY LIMITED |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Controller of Flip Flop Drone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2475.0 |
EAS Grant - Application Zrbww7Fs3Oh5CWL6YgtEOg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ZEGO ELECTRONIC COMPANY LIMITED ROOM 703, KOWLOON BUILDING, 555 NATHAN ROAD, KOWLOON, Hong Kong |
Date of Grant: 07/11/2016 Application Dated: 07/11/2016 |
| Attention: JADE WANG , VICE-GENERAL MANAGER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACS612TX |
| Name of Grantee: | ZEGO ELECTRONIC COMPANY LIMITED |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Controller of Flip Flop Drone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2475.0 |
| Mail To: |
