FCC ID 2ACS620RX
Copter of Alpha Drone Pro
by ZEGO ELECTRONIC COMPANY LIMITED
Grantee Code: 2ACS6 Product Code: 20RX
Latest application date: 2016-10-25
Device Images
FCC ID Device Details
| FCC ID | 2ACS620RX |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACS6 |
| Product Code | 20RX |
| Applicant Business | ZEGO ELECTRONIC COMPANY LIMITED |
| Related Domains |  yrtoys.com |
| Equipment Class | Copter of Alpha Drone Pro |
| Test Firm | CMA Industrial Development Foundation Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2475 MHz | Original Equipment | 2016-10-25 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-10-25 | PDF 4.3 MB |
| Internal Photos | Internal Photos | 2016-10-25 | PDF 1.2 MB |
| External Photos | External Photos | 2016-10-25 | PDF 824 KB |
| Label Sample | ID Label/Location Info | 2016-10-25 | PDF 149.5 KB |
| Test Setup Photos | Test Setup Photos | 2016-10-25 | PDF 878.6 KB |
| Test Report | Test Report | 2016-10-25 | PDF 5.8 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-10-25 | PDF 29.9 KB |
| Letter for Remove FCC Statement | Cover Letter(s) | 2016-10-25 | PDF 177.9 KB |
| Opeation Declara Letter | Cover Letter(s) | 2016-10-25 | PDF 29.4 KB |
| POA | Cover Letter(s) | 2016-10-25 | PDF 30.1 KB |
| MRE Report | RF Exposure Info | 2016-10-25 | PDF 29 KB |
| Block Diagram Metadata only | Block Diagram | PDF 97.8 KB | |
| Schematics Metadata only | Schematics | PDF 1.4 MB | |
| Operational Description Metadata only | Operational Description | PDF 4.7 KB |
Application Information
| Application ID | NoQ16eeBhUIUifTMi7qCoA== |
|---|---|
| Final Action Date | 2016-10-25 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023807795 |
| Model | 20RX |
| Frequency Range | 2402-2475 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Copter of Alpha Drone Pro |
| Responsible Party | JADE WANG, VICE-GENERAL MANAGER, jadewang@yrtoys.com , (86) 755-27062168 |
| Test Firm | Joey Kwok, CMA Industrial Development Foundation Limited, joeykwok@cmatesting.org  , +852 2690 8255 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. The antenna installation and operating configurations of this transmitter, including any applicable antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| NoQ16eeBhUIUifTMi7qCoA== | 2016-10-25 | Original Equipment |
Grants
TCB Grant - Application NoQ16eeBhUIUifTMi7qCoA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/25/2016 Application Dated: 10/25/2016 |
| ZEGO ELECTRONIC COMPANY LIMITED |
| ROOM 703, KOWLOON BUILDING, |
| 555 NATHAN ROAD, |
| KOWLOON, Hong Kong |
| Attention: JADE WANG , VICE-GENERAL MANAGER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACS620RX |
| Name of Grantee: | ZEGO ELECTRONIC COMPANY LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | Copter of Alpha Drone Pro |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2475.0 | 0.000139 | |||
| 15C | 2412.0 - 2462.0 | 0.004928 |
| Power listed is conducted. The antenna installation and operating configurations of this transmitter, including any applicable antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
EAS Grant - Application NoQ16eeBhUIUifTMi7qCoA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ZEGO ELECTRONIC COMPANY LIMITED ROOM 703, KOWLOON BUILDING, 555 NATHAN ROAD, KOWLOON, Hong Kong |
Date of Grant: 10/25/2016 Application Dated: 10/25/2016 |
| Attention: JADE WANG , VICE-GENERAL MANAGER |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACS620RX |
| Name of Grantee: | ZEGO ELECTRONIC COMPANY LIMITED |
| Equipment Class: | Digital Transmission System |
| Notes: | Copter of Alpha Drone Pro |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2475.0 | 0.000139 | |||
| 15C | 2412.0 - 2462.0 | 0.004928 |
| Power listed is conducted. The antenna installation and operating configurations of this transmitter, including any applicable antenna gain and cable loss must satisfy MPE categorical Exclusion Requirements of §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
| Mail To: |
