FCC ID 2ACSV-HF-LPB120
HF-LPB120
by High-Flying Electronics Technology Co., Ltd.
Grantee Code: 2ACSV Product Code: HFLPB120
Latest application date: 2016-04-06
Device Images
FCC ID Device Details
| FCC ID | 2ACSV-HF-LPB120 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACSV |
| Product Code | HFLPB120 |
| Applicant Business | High-Flying Electronics Technology Co., Ltd. 🇨🇳 |
| Related Domains |  hi-flying.com |
| Equipment Class | HF-LPB120 |
| Test Firm | Shenzhen Anbotek Compliance Laboratory Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-04-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-04-06 | PDF 571.2 KB |
| Int photo | Internal Photos | 2016-04-06 | PDF 155.6 KB |
| Ext photo | External Photos | 2016-04-06 | PDF 240.2 KB |
| ID label | ID Label/Location Info | 2016-04-06 | PDF 9.1 KB |
| ID label location | ID Label/Location Info | 2016-04-06 | PDF 64.3 KB |
| Test setup photo | Test Setup Photos | 2016-04-06 | PDF 106.4 KB |
| Test report | Test Report | 2016-04-06 | PDF 3.8 MB |
| Confidential request letter | Cover Letter(s) | 2016-04-06 | PDF 20.7 KB |
| Modular approval letter | Cover Letter(s) | 2016-04-06 | PDF 42 KB |
| POA | Cover Letter(s) | 2016-04-06 | PDF 933.2 KB |
| WiFi ch 12-13 letter | Cover Letter(s) | 2016-04-06 | PDF 28.6 KB |
| RF exposure | RF Exposure Info | 2016-04-06 | PDF 30.7 KB |
| Block diagram Metadata only | Block Diagram | PDF 12.8 KB | |
| SCH Metadata only | Schematics | PDF 67.6 KB | |
| OpDes Metadata only | Operational Description | PDF 39.5 KB |
Application Information
| Application ID | 0S6kJLvONoH9r7shDCwBkw== |
|---|---|
| Final Action Date | 2016-04-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023804537 |
| Model | HF-LPB120 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | HF-LPB120 |
| Responsible Party | Sen Xie, General Manager, senxie@hi-flying.com , 400-189-3108 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | TCB@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single Modular Approval for mobile platform Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 0S6kJLvONoH9r7shDCwBkw== | 2016-04-06 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2412-2462 MHz | 0.0653000 | 15C |
Grants
TCB Grant - Application 0S6kJLvONoH9r7shDCwBkw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| High-Flying Electronics Technology Co., Ltd. |
| Building 17, No.1500 Zu Chongzhi Road, |
| Pudong District, |
| Shanghai, 201203 China |
| Attention: Sen Xie , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACSV-HF-LPB120 |
| Name of Grantee: | High-Flying Electronics Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | HF-LPB120 |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0653 |
| Single Modular Approval for mobile platform Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
EAS Grant - Application 0S6kJLvONoH9r7shDCwBkw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
High-Flying Electronics Technology Co., Ltd. Building 17, No.1500 Zu Chongzhi Road, Pudong District, Shanghai, 201203 China |
Date of Grant: 04/06/2016 Application Dated: 04/06/2016 |
| Attention: Sen Xie , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACSV-HF-LPB120 |
| Name of Grantee: | High-Flying Electronics Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | HF-LPB120 |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.0653 |
| Single Modular Approval for mobile platform Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| Mail To: |
