RAT950 T950 Label Diagram - FCC ID 2ACUNRAT950

FCC ID 2ACUNRAT950

Label art

T950

by Red Arch Manufacturing Ltd

Document preview loads when visible.

Document Details

FCC ID2ACUNRAT950
Document ID2426334
Document TypeID Label/Location Info
DescriptionLabel art
ApplicantRed Arch Manufacturing Ltd
Equipment ClassT950
Product CodeRAT950
Application IDDVlG4zOLV5beg6uzDNXu8Q==
Application PurposeOriginal Equipment
Application Date2014-10-24
Frequency Range2402-2480 MHz
FRN0023824279
Test FirmElement Materials Technology Warwick Ltd
Certified ByDr. Michael Gore Senior Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2014-10-24
Available2014-10-24
Created2014-08-26
Modified2014-08-26
Pages1
File TypeAdobe Acrobat PDF
File Size72494
File SHA-256ff44a34e1da6b08dce9a6ccb7d0430e9edb63f7417c9eb598b8b3b3cda4b0744
PDF Metadata AuthorRob
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 2426334
