FCC ID 2ACX8CR6023A
Turntable
by TIMSEN INTERNATIONAL LIMITED
Grantee Code: 2ACX8 Product Code: CR6023A
Latest application date: 2017-03-31
Device Images
FCC ID Device Details
| FCC ID | 2ACX8CR6023A |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ACX8 |
| Product Code | CR6023A |
| Applicant Business | TIMSEN INTERNATIONAL LIMITED 🇨🇳 |
| Related Domains |  timsen.net |
| Equipment Class | Turntable |
| Test Firm | Accurate Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-03-31 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-03-31 | PDF 186.7 KB |
| Internal Photos | Internal Photos | 2017-03-31 | PDF 223.7 KB |
| External Photos | External Photos | 2017-03-31 | PDF 228.1 KB |
| Label & Label Location | ID Label/Location Info | 2017-03-31 | PDF 271.7 KB |
| RF Test Set-up Photos | Test Setup Photos | 2017-03-31 | PDF 700 KB |
| RF Test Report-1 | Test Report | 2017-03-31 | PDF 3 MB |
| RF Test Report-2 | Test Report | 2017-03-31 | PDF 3.7 MB |
| Authorization Letter | Cover Letter(s) | 2017-03-31 | PDF 39.9 KB |
| Family model letter | Cover Letter(s) | 2017-03-31 | PDF 32.5 KB |
| LTC Letter | Cover Letter(s) | 2017-03-31 | PDF 40.3 KB |
| MPE Report | RF Exposure Info | 2017-03-31 | PDF 110.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 45.7 KB | |
| Schematics Metadata only | Schematics | PDF 116.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 170.1 KB |
Application Information
| Application ID | Bqdcm4aewOfL1rGxBPR9QQ== |
|---|---|
| Final Action Date | 2017-03-31 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0023867419 |
| Model | CR6023A |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Turntable |
| Responsible Party | Sherry Au, Manager, sherry@timsen.net , 00862038804750 |
| Test Firm | Sean Liu, Accurate Technology Co., Ltd., sean@atc-lab.com  , 86-75526503291 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output Power listed is conducted. The antennas used for this transmitter must be installed to provide a seperation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| Bqdcm4aewOfL1rGxBPR9QQ== | 2017-03-31 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0033000 | 15C |
Grants
TCB Grant - Application Bqdcm4aewOfL1rGxBPR9QQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 03/31/2017 Application Dated: 03/29/2017 |
| TIMSEN INTERNATIONAL LIMITED |
| 5F, No. 447, Tianhebei Road |
| Tianhe District, Guangzhou |
| Guangdong Province, 510610 China |
| Attention: Sherry Au , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACX8CR6023A |
| Name of Grantee: | TIMSEN INTERNATIONAL LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Turntable |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0033 |
| Output Power listed is conducted. The antennas used for this transmitter must be installed to provide a seperation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance |
EAS Grant - Application Bqdcm4aewOfL1rGxBPR9QQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
TIMSEN INTERNATIONAL LIMITED 5F, No. 447, Tianhebei Road Tianhe District, Guangzhou Guangdong Province, 510610 China |
Date of Grant: 03/31/2017 Application Dated: 03/29/2017 |
| Attention: Sherry Au , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ACX8CR6023A |
| Name of Grantee: | TIMSEN INTERNATIONAL LIMITED |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Turntable |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.0033 |
| Output Power listed is conducted. The antennas used for this transmitter must be installed to provide a seperation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance |
