PWB100 Croise.E Urban Band Test Setup Photos - FCC ID 2AD5K-PWB100

FCC ID 2AD5K-PWB100

Test setup photos

Croise.E Urban Band

by PARTRON CO., LTD

Document preview loads when visible.

Document Details

FCC ID2AD5K-PWB100
Document ID2771097
Document TypeTest Setup Photos
DescriptionTest setup photos
Document TitleSetup Photos_PWB-100_REV.1x
ApplicantPARTRON CO., LTD
Equipment ClassCroise.E Urban Band
Product CodePWB100
Application IDX7cjxt2okmHYekbphj2EGg==
Application PurposeOriginal Equipment
Application Date2015-10-02
Frequency Range2402-2480 MHz
FRN0024246720
Test FirmSGS Korea Co., Ltd.
Certified ByJi-Hong Park
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/30/2016
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-10-02
Available2016-03-30
Created2015-10-01
Modified2015-10-01
Pages4
File TypeAdobe Acrobat PDF
File Size365865
File SHA-25682820ed421bdcc5325cf55b238cca2d33433d0ff5424f649f7d4daa5c1dddcf6
PDF Metadata Authorgihee_hwang
PDF Metadata ProducerGaaiho PDF gihee_hwang
FCC.gov SourcesFCC.gov 2771097
