GC03249102 UFO Test Setup Photos - FCC ID 2AD6LGC03249102
FCC ID 2AD6LGC03249102
setup photos-revised
UFO
Document preview loads when visible.
Document Details
| FCC ID | 2AD6LGC03249102 |
|---|---|
| Document ID | 3047646 |
| Document Type | Test Setup Photos |
| Description | setup photos-revised |
| Document Title | setup photos |
| Applicant | Guangdong Cheerson Hobby Technology Co., Ltd. |
| Equipment Class | UFO |
| Product Code | GC03249102 |
| Application ID | D7LYPI0LE6x/YMozM/srHg== |
| Application Purpose | Original Equipment |
| Application Date | 2016-07-01 |
| Frequency Range | 5745-5865 MHz |
| FRN | 0024264319 |
| Test Firm | SGS-CSTC Standards Technical Services Co.,Ltd. |
| Certified By | Vicky Yuan |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 2016-07-01 |
| Available | 2016-07-01 |
| Created | 2016-06-28 |
| Modified | 2016-06-28 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 269374 |
| File SHA-256 | c8f13327c5b2004396b2a10f00148ef7a0bced2b80fb9176ce9eff17db8edf06 |
| PDF Metadata Author | joyce_shi |
| PDF Metadata Producer | GPL Ghostscript 8.64 PScript5.dll Version 5.2.2 |
| FCC.gov Sources | FCC.gov 3047646 |
