N551 4G LTE SMARTPHONE External Photos - FCC ID 2ADA4N551

FCC ID 2ADA4N551

External Photos

4G LTE SMARTPHONE

by MOBIWIRE MOBILES (NINGBO) CO.,LTD

Document preview loads when visible.

Document Details

FCC ID2ADA4N551
Document ID3125389
Document TypeExternal Photos
DescriptionExternal Photos
Document Title16070816-FCC-E 15B
ApplicantMOBIWIRE MOBILES (NINGBO) CO.,LTD
Equipment Class4G LTE SMARTPHONE
Product CodeN551
Application ID5Q28g5RnOq65ujRHAv89ag==
Application PurposeOriginal Equipment
Application Date2016-09-07
Frequency Range1712.5-1752.5 MHz
FRN0023967144
Test FirmSIEMIC (Shenzhen-China) Laboratories
Certified ByXu Leander
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-09-07
Available2016-09-07
Created2016-08-31
Modified2016-08-31
Pages2
File TypeAdobe Acrobat PDF
File Size313604
File SHA-256fac4c6e75db0b6489905fb2e4bac5fe0cb6760a16103f0fae87fedd32b8a1483
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAcrobat Distiller 10.0.0 (Windows) Administrator
FCC.gov SourcesFCC.gov 3125389, FCC.gov 3125367, FCC.gov 3125345, FCC.gov 3125328
