FCC ID 2ADGHCON2005

FCC ID 2ADGHCON2005 Internal-Photos, 2ADGH CON2005, 2ADGHC0N2005, 2ADGHCON2OO5, 2ADGHCON2005, 2ADGHCON200S

Ralinwi Nanjing Electronic Technology Co., Ltd. Embedded WiFi Module CON2005

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: 2ADGHCON2005 is 2ADGH. The remaining characters of the FCC ID, CON2005, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: Embedded WiFi Module

*Please Check Individual Documents for more images

Application: Embedded WiFi Module
Equipment Class: DTS - Digital Transmission System
Short Link: fcc.id/2ADGHCON2005
Sources: FCC.gov | FCC.report
Registered By: Ralinwi Nanjing Electronic Technology Co., Ltd. - 2ADGH (China)

App #	Purpose	Date	Unique ID
1	Original Equipment	2015-10-06	sLC7G/RVOW4uM/72BwmZTg==

Operating Frequencies

Frequency Range	Power Output	Rule Parts	Grant Notes	Line Entry
2.412-2.462 GHz	54 mW	15C	20	1

Exhibits

Document	Type	Submitted Available
Setup r3	Test Setup Photos Adobe Acrobat PDF (131 kB)	2015-10-06 2015-10-06
RF Exposure Info RFx	RF Exposure Info Adobe Acrobat PDF (38 kB)	2015-10-02 2015-10-06
Manual	Users Manual Adobe Acrobat PDF (361 kB)	2015-10-02 2015-10-06
Addendum	Users Manual Adobe Acrobat PDF (30 kB)	2015-10-02 2015-10-06
Label	ID Label/Location Info Adobe Acrobat PDF (64 kB)	2015-10-02 2015-10-06
Internal Photos Int	Internal Photos Adobe Acrobat PDF (154 kB)	2015-10-02 2015-10-06
Modular Request	Cover Letter(s) Adobe Acrobat PDF (182 kB)	2015-10-02 2015-10-06
Confid	Cover Letter(s) Adobe Acrobat PDF (100 kB)	2015-10-02 2015-10-06
Authorization	Cover Letter(s) Adobe Acrobat PDF (94 kB)	2015-10-02 2015-10-06
AdHoc	Cover Letter(s) Adobe Acrobat PDF (96 kB)	2015-10-02 2015-10-06
External Photos Ext	External Photos Adobe Acrobat PDF (108 kB)	2015-10-02 2015-10-06
Test Report DTS	Test Report Adobe Acrobat PDF (2633 kB)	2015-10-02 2015-10-06
Test Report Ops	Operational Description Adobe Acrobat PDF (113 kB)	2015-10-02
Schema	Schematics Adobe Acrobat PDF (78 kB)	2015-10-02
Block	Block Diagram Adobe Acrobat PDF (59 kB)	2015-10-02

Application Forms

1 (2015-10-06)

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	Ralinwi Nanjing Electronic Technology Co., Ltd.
FCC Registration Number (FRN):	0024834301
Alphanumeric FCC ID:	2ADGHCON2005
Unique Application Identifier:	sLC7G/RVOW4uM/72BwmZTg==
Line one:	Room 404,Building 6,No.6 Su Yuan Road,
Line two:	Xuanwu District
City:	Nanjing
State:	N/A
Country:	China

TCB Information

TCB Application Email Address:	certification@micomlabs.com
TCB Scope:	A4: UNII devices & low power transmitters using spread spectrum techniques

FCC ID

Grantee Code:	2ADGH
Product Code:	CON2005

Person at the applicant's address to receive grant or for contact

Name:	Zuokun Liang
Title:	product manager

Telephone Number:

+86-25-68520225

Extension:

Fax Number:	+86-25-68205771
Email:	liangzuokun@ralinwi.com

Technical Contact

Firm Name:	Teleconformity
First Name:	Mark
Last Name:	Koop
Line 1:	Rietven 31
City:	Enschede, Overyssel
Country:	Netherlands
Zip Code:	7534NH

Telephone Number:

(31)848395867

Extension:

Fax Number:	(31)848362566
E-Mail:	mark.koop@teleconformity.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: No

If so, specify the short-term confidentiality release date (MM/DD/YYYY format):
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: DTS - Digital Transmission System
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	Embedded WiFi Module

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? No

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Shenzhen BCTC Technology Co., Ltd.

First Name: James

Last Name: Zhang

Telephone Number:

86-755-33640208

Extension:

Fax Number: 86-755-33229357

E-mail: jams.zhang@btc-lab.com

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Modular Approval. Power Output listed is Conducted. This Grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503).

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes.

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements.

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time.

Signature of Authorized Person Filing: Mark Koop

Title of authorized signature: Manager

Applications are submitted for FCC ID and Grant requests. Click an above application to view details

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

MiCOM Labs
575 Boulder Court
Pleasanton, CA 94566

Date of Grant: 10/06/2015

Application Dated: 10/02/2015

Ralinwi Nanjing Electronic Technology Co., Ltd.

Room 404,Building 6,No.6 Su Yuan Road,

Xuanwu District

Nanjing,
China

Attention: Zuokun Liang , product manager

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ADGHCON2005

Name of Grantee:	Ralinwi Nanjing Electronic Technology Co., Ltd.

Equipment Class:	Digital Transmission System
Notes:	Embedded WiFi Module

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
20	15C	2412.0 - 2462.0	0.054

Modular Approval. Power Output listed is Conducted. This Grant is valid only when the device is sold to OEM integrators and the OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except in accordance with accepted multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

20:	All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed.
