CW601G OBD Telematics Dongle Test Setup... - FCC ID 2ADKG-CW-601G

FCC ID 2ADKG-CW-601G

Test Setup Photos

OBD Telematics Dongle

by Shenzhen Chainway ITS Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2ADKG-CW-601G
Document ID2457331
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantShenzhen Chainway ITS Co., Ltd.
Equipment ClassOBD Telematics Dongle
Product CodeCW601G
Application IDRgl29rdbk5Fx/1oOSsmhQg==
Application PurposeOriginal Equipment
Application Date2014-11-27
Frequency Range1850.2-1909.8 MHz
FRN0024074999
Test FirmCCIC-SET
Certified ByShengni Zhou
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2014-11-27
Available2014-11-27
Created2014-11-19
Modified2014-11-19
Pages1
File TypeAdobe Acrobat PDF
File Size271309
File SHA-2564222de8562996c4745189d045a0afca035c3afd0b9bc595f16be9f73a1f565b3
PDF Metadata Author微软用户
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 2457331
