FCC ID 2ADQZTPD5X
DMR Digital Portable Radio
by Quanshun Communication Technology Co., Ltd
Grantee Code: 2ADQZ Product Code: TPD5X
Latest application date: 2016-08-05
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 400-406 MHz | Original Equipment | 2016-08-05 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-08-05 | PDF 379.3 KB |
| Internal Photos | Internal Photos | 2016-08-05 | PDF 507.1 KB |
| External Photos | External Photos | 2016-08-05 | PDF 591.2 KB |
| Label ID and Location Info | ID Label/Location Info | 2016-08-05 | PDF 163.1 KB |
| SAR Test Setup Photos | Test Setup Photos | 2016-08-05 | PDF 552.7 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-05 | PDF 218.6 KB |
| Test Report Part 1 | Test Report | 2016-08-05 | PDF 4.3 MB |
| Test Report Part 2 | Test Report | 2016-08-05 | PDF 2 MB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-08-05 | PDF 19.4 KB |
| Frequency extend letter | Cover Letter(s) | 2016-08-05 | PDF 64.8 KB |
| Narrowband requirement | Cover Letter(s) | 2016-08-05 | PDF 68.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 7.1 KB | |
| Schematics Metadata only | Schematics | PDF 219.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 78.1 KB | |
| Part List Metadata only | Parts List/Tune Up Info | PDF 28.3 KB | |
| Tune Up Info Metadata only | Parts List/Tune Up Info | PDF 377.9 KB |
Application Information
| Application ID | fOwXqtH+zkRUn7abfw4cVQ== |
|---|---|
| Final Action Date | 2016-08-05 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024131914 |
| Model | TPD5X |
| Frequency Range | 400-406 MHz |
| Equipment Class | TNF - Licensed Non-Broadcast Transmitter Held to Face |
| Device Description | DMR Digital Portable Radio |
| Responsible Party | Roger Chen, Manager, roger@qstx.com  , (86 595) 86753355 |
| Test Firm | Gavin Liang, Shenzhen LCS Compliance Testing Laboratory Ltd., Gavin.liang@lcs-cert.com  , 86-0755-82591330 |
| TCB Email | TCB@cetecom.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is peak conducted. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled SAR limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. SAR compliance for body-worn operating configurations is limited to the specific belt-clip, holster, and accessories tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR levels for Head and Body-Worn accessories are 2.71 W/kg and 5.94 W/kg respectively for a 50% Duty Cycle. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| fOwXqtH+zkRUn7abfw4cVQ== | 2016-08-05 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 400-406 MHz | 4.732 | 0.95ppm | 11K0F3E | 9 | BF, EF, ES |
| 400-406 MHz | 4.634 | 0.69ppm | 7K60FXD | 9 | BF, EF, ES |
| 400-406 MHz | 4.634 | 0.69ppm | 7K60FXW | 9 | BF, EF, ES |
| 406.1-470 MHz | 4.732 | 0.95ppm | 11K0F3E | 9 | BF, EF, ES |
| 406.1-470 MHz | 4.634 | 0.69ppm | 7K60FXD | 9 | BF, EF, ES |
| 406.1-470 MHz | 4.634 | 0.69ppm | 7K60FXW | 9 | BF, EF, ES |
Grants
TCB Grant - Application fOwXqtH+zkRUn7abfw4cVQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CTC advanced GmbH Untertuerkheimer Strasse 6-10 66117 Saarbruecken, Germany |
Date of Grant: 08/05/2016 Application Dated: 08/05/2016 |
| Quanshun Communication Technology Co., Ltd |
| Quanshun Bldg., Daxiamei, Nan'an, |
| Quanzhou, Fujian,, China |
| Attention: Roger Chen , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ADQZTPD5X |
| Name of Grantee: | Quanshun Communication Technology Co., Ltd |
| Equipment Class: | Licensed Non-Broadcast Transmitter Held to Face |
| Notes: | DMR Digital Portable Radio |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BF EF ES | 90 | 400.0 - 406.0 | 4.732 | 0.95 PM | 11K0F3E |
| BF EF ES | 90 | 400.0 - 406.0 | 4.634 | 0.69 PM | 7K60FXD |
| BF EF ES | 90 | 400.0 - 406.0 | 4.634 | 0.69 PM | 7K60FXW |
| BF EF ES | 90 | 406.1 - 470.0 | 4.732 | 0.95 PM | 11K0F3E |
| BF EF ES | 90 | 406.1 - 470.0 | 4.634 | 0.69 PM | 7K60FXD |
| BF EF ES | 90 | 406.1 - 470.0 | 4.634 | 0.69 PM | 7K60FXW |
| Output power listed is peak conducted. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled SAR limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. SAR compliance for body-worn operating configurations is limited to the specific belt-clip, holster, and accessories tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR levels for Head and Body-Worn accessories are 2.71 W/kg and 5.94 W/kg respectively for a 50% Duty Cycle. |
| BF: | The output power is continuously variable from the value listed in this entry to 20%-25% of the value listed. |
| EF: | This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization. |
| ES: | This equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. |
EAS Grant - Application fOwXqtH+zkRUn7abfw4cVQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quanshun Communication Technology Co., Ltd Quanshun Bldg., Daxiamei, Nan'an, Quanzhou, Fujian,, China |
Date of Grant: 08/05/2016 Application Dated: 08/05/2016 |
| Attention: Roger Chen , Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2ADQZTPD5X |
| Name of Grantee: | Quanshun Communication Technology Co., Ltd |
| Equipment Class: | Licensed Non-Broadcast Transmitter Held to Face |
| Notes: | DMR Digital Portable Radio |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BF EF ES | 90 | 400.0 - 406.0 | 4.732 | 0.95 PM | 11K0F3E |
| BF EF ES | 90 | 400.0 - 406.0 | 4.634 | 0.69 PM | 7K60FXD |
| BF EF ES | 90 | 400.0 - 406.0 | 4.634 | 0.69 PM | 7K60FXW |
| BF EF ES | 90 | 406.1 - 470.0 | 4.732 | 0.95 PM | 11K0F3E |
| BF EF ES | 90 | 406.1 - 470.0 | 4.634 | 0.69 PM | 7K60FXD |
| BF EF ES | 90 | 406.1 - 470.0 | 4.634 | 0.69 PM | 7K60FXW |
| Output power listed is peak conducted. This device must be restricted to work related operations in an Occupational/Controlled RF exposure Environment, not exceeding a maximum transmitting duty factor of 50%. All qualified end-users of this device must have the knowledge to control their exposure conditions and/or duration to comply with the Occupational/Controlled SAR limit and requirements. A label, as described in this filing, must be displayed on the device to direct users to specific training information for meeting Occupational Exposure Requirements. SAR compliance for body-worn operating configurations is limited to the specific belt-clip, holster, and accessories tested for this filing. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR levels for Head and Body-Worn accessories are 2.71 W/kg and 5.94 W/kg respectively for a 50% Duty Cycle. |
| BF: | The output power is continuously variable from the value listed in this entry to 20%-25% of the value listed. |
| EF: | This device may contain functions that are not operational in U.S Territories except as noted in the filing. This grant has extended frequencies as noted in the filing and Section 2.927(b) applies to this authorization. |
| ES: | This equipment is capable of supporting a minimum data rate of 4800 bits per second per 6.25 kHz of channel bandwidth. |
