PSPCL21A0 Mobile Phone Test Report - FCC ID 2ADWUPSPCL21A0
FCC ID 2ADWUPSPCL21A0
Test report
Mobile Phone
Document preview loads when visible.
Document Details
| FCC ID | 2ADWUPSPCL21A0 |
|---|---|
| Document ID | 3961589 |
| Document Type | Test Report |
| Description | Test report |
| Document Title | HD 271 S1 |
| Applicant | ONE DIAMOND ELECTRONICS INC. |
| Equipment Class | Mobile Phone |
| Product Code | PSPCL21A0 |
| Application ID | 4EIhuqNRVppX1vAjPuuukw== |
| Application Purpose | Original Equipment |
| Application Date | 2018-08-13 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0024180390 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Bruce Zhang EMC Laboratory Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2018-08-13 |
| Available | 2018-08-13 |
| Created | 2018-08-01 |
| Modified | 2018-08-01 |
| Pages | 31 |
| File Type | Adobe Acrobat PDF |
| File Size | 4798484 |
| File SHA-256 | e88fab6ebf7e586320ace62bc984942addefb6fcbf5db9e5cdbf98f9e772769e |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | LAB02 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 3961589, FCC.gov 3961588 |
