BC1 Mobile Phone Test Setup Photos - FCC ID 2ADYY-BC1
FCC ID 2ADYY-BC1
Test setup
Mobile Phone
Document preview loads when visible.
Document Details
| FCC ID | 2ADYY-BC1 |
|---|---|
| Document ID | 4879847 |
| Document Type | Test Setup Photos |
| Description | Test setup |
| Document Title | HD 271 S1 |
| Applicant | TECNO MOBILE LIMITED |
| Equipment Class | Mobile Phone |
| Product Code | BC1 |
| Application ID | EgyY5NA3NByqfdOftFBbWw== |
| Application Purpose | Original Equipment |
| Application Date | 2020-08-30 |
| Frequency Range | 1850.2-1909.8 MHz |
| FRN | 0024206328 |
| Test Firm | JianYan Testing Group Shenzhen Co., Ltd. |
| Certified By | Bruce Zhang EMC Laboratory Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 02/26/2021 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2020-08-30 |
| Available | 2021-02-26 |
| Created | 2020-08-28 |
| Modified | 2020-08-28 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 279827 |
| File SHA-256 | c86fef4937486652fc0ffe0f74cbddb28cdefb29967f45443eed9a8d36e6e0e8 |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | LAB02 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 4879847 |
