G240WFV2 7368 ISAM GPON ONU Test Setup Photos - FCC ID 2ADZRG240WFV2

FCC ID 2ADZRG240WFV2

Test setup

7368 ISAM GPON ONU

by Nokia Shanghai Bell Co. Ltd.

Document preview loads when visible.

Document Details

FCC ID2ADZRG240WFV2
Document ID3613432
Document TypeTest Setup Photos
DescriptionTest setup
Document Title2ADZRG240WFV2_Test photo Part15C Rev1x
ApplicantNokia Shanghai Bell Co. Ltd.
Equipment Class7368 ISAM GPON ONU
Product CodeG240WFV2
Application IDzSi5t5itA8OWHdj+HAulgg==
Application PurposeOriginal Equipment
Application Date2017-10-22
Frequency Range2412-2462 MHz
FRN0024217564
Test FirmTA Technology (Shanghai) Co., Ltd.
Certified ByLiguo Leng Hardware Consultant Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-10-22
Available2017-10-22
Created2017-10-19
Modified2017-10-19
Pages2
File TypeAdobe Acrobat PDF
File Size159586
File SHA-2567b3ef111f138214e480a9701e6069ce19ffcdad79ffd36c4c34287c342a6d521
PDF Metadata Authorhaojinhua
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows) haojinhua
FCC.gov SourcesFCC.gov 3613432
