FCC ID 2ADZRXS250WXA
XGSPON ONU
by Nokia Shanghai Bell Co. Ltd.
Grantee Code: 2ADZR Product Code: XS250WXA
Latest application date: 2017-04-01
Device Images
FCC ID Device Details
| FCC ID | 2ADZRXS250WXA |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2ADZR |
| Product Code | XS250WXA |
| Applicant Business | Nokia Shanghai Bell Co. Ltd. 🇨🇳 |
| Related Domains |  nokia-sbell.com |
| Equipment Class | XGSPON ONU |
| Test Firm | TA Technology (Shanghai) Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2017-04-01 |
| 5180-5240 MHz | Original Equipment | 2017-04-01 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2017-04-01 | PDF 3.5 MB |
| Internal Photos | Internal Photos | 2017-04-01 | PDF 848.7 KB |
| External Photos | External Photos | 2017-04-01 | PDF 411.2 KB |
| Label | ID Label/Location Info | 2017-04-01 | PDF 485.3 KB |
| Test Set Up Photos | Test Setup Photos | 2017-04-01 | PDF 407.5 KB |
| Test Set Up Photos | Test Setup Photos | 2017-04-01 | PDF 230 KB |
| Test Report Metadata only | Test Report | 2017-04-01 | PDF 4.3 MB |
| Test Report Metadata only | Test Report | 2017-04-01 | PDF 5.3 MB |
| Test Report Metadata only | Test Report | 2017-04-01 | PDF 1.3 MB |
| Test report | Test Report | 2017-04-01 | PDF 1.3 MB |
| Test report part 1 | Test Report | 2017-04-01 | PDF 5 MB |
| Test report part 1 | Test Report | 2017-04-01 | PDF 4.3 MB |
| Test report part 2 | Test Report | 2017-04-01 | PDF 4.4 MB |
| Test report part 2 | Test Report | 2017-04-01 | PDF 2.8 MB |
| Test report part 3 | Test Report | 2017-04-01 | PDF 5.3 MB |
| Confidentiality | Cover Letter(s) | 2017-04-01 | PDF 21.9 KB |
| Declaration | Cover Letter(s) | 2017-04-01 | PDF 81.1 KB |
| Declaration Letter | Cover Letter(s) | 2017-04-01 | PDF 81.1 KB |
| POA | Cover Letter(s) | 2017-04-01 | PDF 12.6 KB |
| RF Exposure | RF Exposure Info | 2017-04-01 | PDF 307.5 KB |
| SAR Report Metadata only | RF Exposure Info | 2017-04-01 | PDF 307.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 33.7 KB | |
| Schematics Metadata only | Schematics | PDF 2.6 MB | |
| Operational Description Metadata only | Operational Description | PDF 133.5 KB | |
| Software security Metadata only | SDR Software/Security Inf | PDF 133.5 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 234.2 KB | |
| Tune Up Metadata only | Parts List/Tune Up Info | PDF 70.2 KB | |
| Tune Up Procedure Metadata only | Parts List/Tune Up Info | PDF 70.2 KB | |
| Tune Up Procedures Metadata only | Parts List/Tune Up Info | PDF 70.2 KB |
Application Information
| Application ID | uHTGt8er7FNQFxpDCTTBEg== |
|---|---|
| Final Action Date | 2017-04-01 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024217564 |
| Model | XS250WXA |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | XGSPON ONU |
| Responsible Party | Yong Tu, Hardware Advisory engineer, yong.tu@nokia-sbell.com , 86-21-38439795 |
| Test Firm | Zhihui Liu, TA Technology (Shanghai) Co., Ltd., liuzhihui@ta-shanghai.com  , 86-21-50791141 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. The antennas(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20MHz and 40 MHz bandwidth modes. |
