FCC ID 2AE3WEXTWAP100AC
2.4GHz b/g/n, 5GHz ac/a/n Indoor AP
by Extron Electronics
Grantee Code: 2AE3W Product Code: EXTWAP100AC
Latest application date: 2016-10-11
Device Images
FCC ID Device Details
| FCC ID | 2AE3WEXTWAP100AC |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AE3W |
| Product Code | EXTWAP100AC |
| Applicant Business | Extron Electronics 🇺🇸 |
| Related Domains |  extron.com |
| Equipment Class | 2.4GHz b/g/n, 5GHz ac/a/n Indoor AP |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-10-11 |
| 5180-5240 MHz | Original Equipment | 2016-10-11 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-10-11 | PDF 3.5 MB |
| User Manuel | Users Manual | 2016-10-11 | PDF 3.5 MB |
| Internal Photos | Internal Photos | 2016-10-11 | PDF 5.6 MB |
| External Photos | External Photos | 2016-10-11 | PDF 982 KB |
| Label Sample | ID Label/Location Info | 2016-10-11 | PDF 34.4 KB |
| Label-Location | ID Label/Location Info | 2016-10-11 | PDF 69.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-10-11 | PDF 448.9 KB |
| Test Report | Test Report | 2016-10-11 | PDF 975.3 KB |
| Test Report NII | Test Report | 2016-10-11 | PDF 660.2 KB |
| Attestation Letter | Cover Letter(s) | 2016-10-11 | PDF 64.2 KB |
| Agent Authorization letter | Cover Letter(s) | 2016-10-11 | PDF 72.7 KB |
| Confidentiality Request | Cover Letter(s) | 2016-10-11 | PDF 75.8 KB |
| RF Exposure Info MPE | RF Exposure Info | 2016-10-11 | PDF 144 KB |
| Block Diagram Metadata only | Block Diagram | PDF 16.3 KB | |
| Block Diagram (module) Metadata only | Block Diagram | PDF 14.9 KB | |
| Schematics Metadata only | Schematics | PDF 429.5 KB | |
| Schematics (module) Metadata only | Schematics | PDF 116.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 26.8 KB | |
| Software Operating Description Metadata only | SDR Software/Security Inf | PDF 128.7 KB |
Application Information
| Application ID | aYiJ4uDFsxMrIh5WyWilcw== |
|---|---|
| Final Action Date | 2016-10-11 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019024124 |
| Model | EXTWAP100AC |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | 2.4GHz b/g/n, 5GHz ac/a/n Indoor AP |
| Responsible Party | Homi Ahmadi, Director of Compliance Engineering, hahmadi@extron.com , 714-491-1500 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, and 40MHz bandwidth modes. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| aYiJ4uDFsxMrIh5WyWilcw== | 2016-10-11 | Original Equipment |
| KRX0qZdWbAtNKLiK1PQFkg== | 2016-10-11 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application KRX0qZdWbAtNKLiK1PQFkg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 Newberry, FL 32669 |
Date of Grant: 10/11/2016 Application Dated: 10/10/2016 |
| Extron Electronics |
| 1025 E. Ball Road |
| Anaheim, CA 92805 |
| Attention: Homi Ahmadi , Director of Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AE3WEXTWAP100AC |
| Name of Grantee: | Extron Electronics |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 2.4GHz b/g/n, 5GHz ac/a/n Indoor AP |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.685 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.357 |
| Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application KRX0qZdWbAtNKLiK1PQFkg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Extron Electronics 1025 E. Ball Road Anaheim, CA 92805 United States |
Date of Grant: 10/11/2016 Application Dated: 10/10/2016 |
| Attention: Homi Ahmadi , Director of Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AE3WEXTWAP100AC |
| Name of Grantee: | Extron Electronics |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 2.4GHz b/g/n, 5GHz ac/a/n Indoor AP |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.685 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.357 |
| Power listed is maximum combined conducted output power. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 25 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has 20, 40, and 80 MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
