FCC ID 2AE6GUHF-10HHM
Wireless Microphone
by Innovative Concepts and Design LLC
Grantee Code: 2AE6G Product Code: UHF10HHM
Latest application date: 2016-07-23
Device Images
FCC ID Device Details
| FCC ID | 2AE6GUHF-10HHM |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AE6G |
| Product Code | UHF10HHM |
| Applicant Business | Innovative Concepts and Design LLC 🇺🇸 |
| Related Domains |  geminisound.com |
| Equipment Class | Wireless Microphone |
| Test Firm | Dongguan Precise Testing Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 517.6 MHz | Original Equipment | 2016-07-23 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_UHF-10HHM UserMan, r1.pdf | Users Manual | 2016-07-23 | PDF 638 KB |
| 09_UHF-10HHM IntPho.pdf | Internal Photos | 2016-07-23 | PDF 625.5 KB |
| 08_UHF-10HHM ExtPho.pdf | External Photos | 2016-07-23 | PDF 718.2 KB |
| 06-07_UHF-10HHM LabelSmpl-Loc, r1.pdf | ID Label/Location Info | 2016-07-23 | PDF 222 KB |
| 17_UHF-10HHM AntSpec.pdf | Operational Description | 2016-07-23 | PDF 14.8 KB |
| 10_UHF-10HHM TSup.pdf | Test Setup Photos | 2016-07-23 | PDF 109.9 KB |
| 14_UHF-10HHM TestRpt.pdf | Test Report | 2016-07-23 | PDF 1.8 MB |
| 18_UHF-10HHM RFExp.pdf | RF Exposure Info | 2016-07-23 | PDF 76.9 KB |
| 12_UHF-10HHM BlkDia.pdf Metadata only | Block Diagram | PDF 15.5 KB | |
| 13_UHF-10HHM Schem.pdf Metadata only | Schematics | PDF 24.3 KB | |
| 11_UHF-10HHM OpDes, r1.pdf Metadata only | Operational Description | PDF 63.5 KB | |
| 16_UHF-10HHM PartsLst.pdf Metadata only | Parts List/Tune Up Info | PDF 7.5 KB | |
| 21_UHF-10HHM TunPro.pdf Metadata only | Parts List/Tune Up Info | PDF 113.1 KB |
Application Information
| Application ID | 8JpCF3uNLiTleikIYWqjXg== |
|---|---|
| Final Action Date | 2016-07-23 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024703647 |
| Model | UHF-10HHM |
| Frequency Range | 517.6 MHz |
| Equipment Class | TBF - Licensed Broadcast Transmitter Held to Face |
| Device Description | Wireless Microphone |
| Responsible Party | Artie Cabasso, artie@geminisound.com , +1.732.520.5980 |
| Test Firm | Chris Du, Dongguan Precise Testing Service Co., Ltd., chris.du@pts-testing.com  , 86-769-8928-2919 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | B2: General Mobile Radio And Broadcast Services equipment in the following 47 CFR Parts 22 (non-cellular) 73, 74, 90, 95, 97, & 101 (all below 3 GHz) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 8JpCF3uNLiTleikIYWqjXg== | 2016-07-23 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application 8JpCF3uNLiTleikIYWqjXg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Product Service GmbH Storkower Strasse 38c D-15526 Reichenwalde, Germany |
Date of Grant: 07/23/2016 Application Dated: 07/23/2016 |
| Innovative Concepts and Design LLC |
| 458 FLORIDA GROVE ROAD |
| PERTH AMBOY, NJ 08861 |
| Attention: Artie Cabasso |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AE6GUHF-10HHM |
| Name of Grantee: | Innovative Concepts and Design LLC |
| Equipment Class: | Licensed Broadcast Transmitter Held to Face |
| Notes: | Wireless Microphone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 74.861 | 517.6 - 517.6 | 0.0096 | 10.0 PM | F3E | |
| 74.861 | 521.5 - 521.5 | 0.0096 | 10.0 PM | F3E | |
| 74.861 | 533.7 - 533.7 | 0.0096 | 10.0 PM | F3E | |
| 74.861 | 537.2 - 537.2 | 0.0096 | 10.0 PM | F3E |
| Power listed is conducted. |
EAS Grant - Application 8JpCF3uNLiTleikIYWqjXg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Innovative Concepts and Design LLC 458 FLORIDA GROVE ROAD PERTH AMBOY, NJ 08861 United States |
Date of Grant: 07/23/2016 Application Dated: 07/23/2016 |
| Attention: Artie Cabasso |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AE6GUHF-10HHM |
| Name of Grantee: | Innovative Concepts and Design LLC |
| Equipment Class: | Licensed Broadcast Transmitter Held to Face |
| Notes: | Wireless Microphone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 74.861 | 517.6 - 517.6 | 0.0096 | 10.0 PM | F3E | |
| 74.861 | 521.5 - 521.5 | 0.0096 | 10.0 PM | F3E | |
| 74.861 | 533.7 - 533.7 | 0.0096 | 10.0 PM | F3E | |
| 74.861 | 537.2 - 537.2 | 0.0096 | 10.0 PM | F3E |
| Power listed is conducted. |
