FCC ID 2AEBL-M2131
Mini video outdoor station
by ABB Xiamen Smart Technology Co., Ltd.
Grantee Code: 2AEBL Product Code: M2131
Latest application date: 2015-12-20
Device Images
FCC ID Device Details
| FCC ID | 2AEBL-M2131 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AEBL |
| Product Code | M2131 |
| Applicant Business | ABB Xiamen Smart Technology Co., Ltd. 🇨🇳 |
| Related Domains |  cn.abb.com |
| Equipment Class | Mini video outdoor station |
| Test Firm | TUV SUD Certification and Testing (China) Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 0.125 MHz | Original Equipment | 2015-12-20 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual | Users Manual | 2015-12-20 | PDF 1.3 MB |
| Internal photos | Internal Photos | 2015-12-20 | PDF 2.1 MB |
| External photos | External Photos | 2015-12-20 | PDF 1,001.6 KB |
| Label and location | ID Label/Location Info | 2015-12-20 | PDF 680.5 KB |
| Operating description | Operational Description | 2015-12-20 | PDF 33.1 KB |
| Setup photos | Test Setup Photos | 2015-12-20 | PDF 577 KB |
| Test report | Test Report | 2015-12-20 | PDF 2.5 MB |
| Authorisation letter | Cover Letter(s) | 2015-12-20 | PDF 90.6 KB |
| Confidentiality letter | Cover Letter(s) | 2015-12-20 | PDF 141.1 KB |
| MPE report | RF Exposure Info | 2015-12-20 | PDF 90 KB |
| Block diagram Metadata only | Block Diagram | PDF 10 KB | |
| Schematics1 Metadata only | Schematics | PDF 2.7 MB | |
| Schematics2 Metadata only | Schematics | PDF 61.9 KB | |
| Schematics3 Metadata only | Schematics | PDF 2.7 MB | |
| Schematics4 Metadata only | Schematics | PDF 57.3 KB | |
| BoM Metadata only | Parts List/Tune Up Info | PDF 357 KB |
Application Information
| Application ID | m8/hnsxHso64ihrU0hfGnA== |
|---|---|
| Final Action Date | 2015-12-20 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024378689 |
| Model | M2131 |
| Frequency Range | 0.125 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Mini video outdoor station |
| Responsible Party | Shanshan Wang, Testing & Laboratory Specialist, sylvia-shanshan.wang@cn.abb.com , +86 592 7616016 |
| Test Firm | Radu Cristian Gosav, TUV SUD Certification and Testing (China) Co., Ltd, radu.gosav@tuv-sud.cn  , 008675533323229 |
| TCB Email | Tom.Twynam@tuv-sud.co.uk  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| m8/hnsxHso64ihrU0hfGnA== | 2015-12-20 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 0.125 MHz | 15C |
