MI1 Mobile Phone Test Setup Photos - FCC ID 2AEBT-MI1

FCC ID 2AEBT-MI1

Test_Setup_photo

Mobile Phone

by Shenzhen Huibaizhou Electronics Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AEBT-MI1
Document ID4754573
Document TypeTest Setup Photos
DescriptionTest_Setup_photo
ApplicantShenzhen Huibaizhou Electronics Co., Ltd.
Equipment ClassMobile Phone
Product CodeMI1
Application IDPHHqDX1CsGVeQzCJFQBHsw==
Application PurposeOriginal Equipment
Application Date2020-06-08
Frequency Range1850.2-1909.8 MHz
FRN0024661555
Test FirmShenzhen LCS Compliance Testing Laboratory Ltd.
Certified ByGavin Liang
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2020-06-08
Available2020-06-08
Created2020-06-08
Modified2020-06-08
Pages5
File TypeAdobe Acrobat PDF
File Size650386
File SHA-2568762c2806a375c60eec50ce2dd33b29a078fd73377f30d104ffed24c819f4f9d
PDF Metadata AuthorTian
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 4754573
