UBIQMESH01HIL HIL Recorder External... - FCC ID 2AEE7UBIQMESH01HIL

FCC ID 2AEE7UBIQMESH01HIL

External Photos

HIL Recorder

by UbiqMesh Techology Co.,Ltd.

Document preview loads when visible.

Document Details

FCC ID2AEE7UBIQMESH01HIL
Document ID2632174
Document TypeExternal Photos
DescriptionExternal Photos
Document TitleBTX-MCU_FCC pics
ApplicantUbiqMesh Techology Co.,Ltd.
Equipment ClassHIL Recorder
Product CodeUBIQMESH01HIL
Application IDtLh8uTD/yfUgwZ8hw2o0Gw==
Application PurposeOriginal Equipment
Application Date2015-06-01
Frequency Range2402-2480 MHz
FRN0024439861
Test FirmWorldwide Testing Services (Taiwan) Co., Ltd.
Certified ByMark Lee Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2015-06-01
Available2015-06-01
Created2015-05-26
Modified2015-05-26
Pages3
File TypeAdobe Acrobat PDF
File Size466719
File SHA-256ff18e3a67007a8eeba3818a20f7444108f2af8514edad4cddaeee2c8b6ed5de8
PDF Metadata AuthorUser
PDF Metadata ProducerUser Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 2632174
