WPT170AT Sidewinder Test Setup Photos - FCC ID 2AEFM-WPT170AT

FCC ID 2AEFM-WPT170AT

Test Setup Photos

Sidewinder

by Gill Electronics

Document preview loads when visible.

Document Details

FCC ID2AEFM-WPT170AT
Document ID2865061
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantGill Electronics
Equipment ClassSidewinder
Product CodeWPT170AT
Application IDCmO6dYYJ3UxruxFgaUp8rQ==
Application PurposeOriginal Equipment
Application Date2016-01-06
Frequency Range2402-2480 MHz
FRN0024024341
Test FirmCTK Co., Ltd.
Certified ByJerry Strandberg
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-01-06
Available2016-01-06
Created2015-10-16
Modified2015-10-16
Pages3
File TypeAdobe Acrobat PDF
File Size687228
File SHA-256a52bc9e7abec8d91213cc01af2af4099a91b9737d17755f012e5a8592eb2b02e
PDF Metadata ProducerdoPDF Ver 7.3 Build 387 (Windows 7 Home Premium Edition (SP 1) - Version: 6.1.7601 (x64))
FCC.gov SourcesFCC.gov 2865061
