FCC ID 2AEJRPC20X
Tire Pressure Monitoring System-C Series
by Picolink Technology Co.,Ltd
Grantee Code: 2AEJR Product Code: PC20X
Latest application date: 2016-10-26
Device Images
FCC ID Device Details
| FCC ID | 2AEJRPC20X |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AEJR |
| Product Code | PC20X |
| Applicant Business | Picolink Technology Co.,Ltd 🇹🇼 |
| Related Domains |  picolink.com.tw  quietek.com |
| Equipment Class | Tire Pressure Monitoring System-C Series |
| Test Firm | DEKRA TESTING AND CERTIFICATION CO., LTD. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 433.92 MHz | Original Equipment | 2016-10-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-10-26 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2016-10-26 | PDF 769.1 KB |
| External Photos | External Photos | 2016-10-26 | PDF 103 KB |
| ID label | ID Label/Location Info | 2016-10-26 | PDF 16.7 KB |
| Label Location | ID Label/Location Info | 2016-10-26 | PDF 60.1 KB |
| Test Setup Photos | Test Setup Photos | 2016-10-26 | PDF 263.1 KB |
| Test Report | Test Report | 2016-10-26 | PDF 642.5 KB |
| Declaration of Conformity FCC subpart 15B | Cover Letter(s) | 2016-10-26 | PDF 123.7 KB |
| Declaration of authorization | Cover Letter(s) | 2016-10-26 | PDF 25.4 KB |
| confidentiality | Cover Letter(s) | 2016-10-26 | PDF 55.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 121.7 KB | |
| Schematics Metadata only | Schematics | PDF 396.1 KB | |
| Operational Description Metadata only | Operational Description | PDF 72.6 KB |
Application Information
| Application ID | CKrkaas/ZM97RzB8xuOkwg== |
|---|---|
| Final Action Date | 2016-10-26 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024506297 |
| Model | PC20X |
| Frequency Range | 433.92 MHz |
| Equipment Class | DSC - Part 15 Security/Remote Control Transmitter |
| Device Description | Tire Pressure Monitoring System-C Series |
| Responsible Party | Tony Lin, Engineer, tony@picolink.com.tw , 886-3-6682695 |
| Agent | Roy Roy Roy, QuieTek Corporation, roywang@quietek.com , 886-3-592-8858 |
| Technical Contact | Sabrina Tsai, QuieTek Corporation, sabrinatsai@quietek.com , 886-3-592-8858 |
| Non-Technical Contact | Milla Wang, QuieTek Corporation, millawang@quietek.com , 886-3-592-8858 |
| Test Firm | Warren Lin, DEKRA TESTING AND CERTIFICATION CO., LTD., warren.lin@dekra.com  , +886-3-582-8001 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| CKrkaas/ZM97RzB8xuOkwg== | 2016-10-26 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 433.92 MHz | 15.231 |
Grants
TCB Grant - Application CKrkaas/ZM97RzB8xuOkwg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 10/26/2016 Application Dated: 10/21/2016 |
| Picolink Technology Co.,Ltd |
| Rm.5, 8F, No.100, Sec. 1, Jiafeng 11th Rd., |
| Zhubei, 302 Taiwan |
| Attention: Tony Lin , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AEJRPC20X |
| Name of Grantee: | Picolink Technology Co.,Ltd |
| Equipment Class: | Part 15 Security/Remote Control Transmitter |
| Notes: | Tire Pressure Monitoring System-C Series |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15.231 | 433.92 - 433.92 |
EAS Grant - Application CKrkaas/ZM97RzB8xuOkwg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Picolink Technology Co.,Ltd Rm.5, 8F, No.100, Sec. 1, Jiafeng 11th Rd., Zhubei, 302 Taiwan |
Date of Grant: 10/26/2016 Application Dated: 10/21/2016 |
| Attention: Tony Lin , Engineer |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AEJRPC20X |
| Name of Grantee: | Picolink Technology Co.,Ltd |
| Equipment Class: | Part 15 Security/Remote Control Transmitter |
| Notes: | Tire Pressure Monitoring System-C Series |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15.231 | 433.92 - 433.92 |
| Mail To: |
