UP TWS Bluetooth Headset Teardown Internal Photos - FCC ID 2AEN5-UP

FCC ID 2AEN5-UP

Internal Photos

TWS Bluetooth Headset

by Urbanista AB

Document preview loads when visible.

Document Details

FCC ID2AEN5-UP
Document ID4518699
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantUrbanista AB
Equipment ClassTWS Bluetooth Headset
Product CodeUP
Application IDX8A3vZdf/E/CcfcK6rihOQ==
Application PurposeOriginal Equipment
Application Date2019-11-18
Frequency Range2402-2480 MHz
FRN0024562381
Test FirmAttestation of Global Compliance (Shenzhen) Co., L
Certified ByRobin Luo General Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2019-11-18
Available2019-11-18
Created2019-11-11
Modified2019-11-11
Pages5
File TypeAdobe Acrobat PDF
File Size1193814
File SHA-256601a55e24c7d78ead58068356456410722eb469cf17d313fd8a96d7642ebfb1e
PDF Metadata AuthorUSER
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 4518699
