CBH508 Bluetooth Earphone Test Setup Photos - FCC ID 2AEUUCBH508

FCC ID 2AEUUCBH508

Setup Photos

Bluetooth Earphone

by ShenZhen HongFa Technology Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AEUUCBH508
Document ID3125964
Document TypeTest Setup Photos
DescriptionSetup Photos
Document TitleTest Setup Photos 15.247 3.0
ApplicantShenZhen HongFa Technology Co., Ltd.
Equipment ClassBluetooth Earphone
Product CodeCBH508
Application IDkMV6JGv1VNDsa7vGsuf2EA==
Application PurposeOriginal Equipment
Application Date2016-09-07
Frequency Range2402-2480 MHz
FRN0024617813
Test FirmBay Area Compliance Laboratories Corp. (Dongguan)
Certified ByKunMing Mo
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-09-07
Available2016-09-07
Created2016-08-30
Modified2016-08-30
Pages2
File TypeAdobe Acrobat PDF
File Size175567
File SHA-2565ab9b94eb18a315e76eca055f7bb6fc4735c2ae3662c28cd8f9ec12828c19b30
PDF Metadata Authorreporter04
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows) reporter04
FCC.gov SourcesFCC.gov 3125964
