W20 Portable Charger Test Setup Photos - FCC ID 2AEZ4-W20

FCC ID 2AEZ4-W20

Test photos

Portable Charger

by Shenzhen Joway Power Supply Co., Ltd.

Document preview loads when visible.

Document Details

FCC ID2AEZ4-W20
Document ID8549677
Document TypeTest Setup Photos
DescriptionTest photos
ApplicantShenzhen Joway Power Supply Co., Ltd.
Equipment ClassPortable Charger
Product CodeW20
Application IDQlUl0kJ2809n8a5pOz5gyw==
Application PurposeOriginal Equipment
Application Date2025-08-07
Frequency Range0.115-0.205 MHz
FRN0029511813
Test FirmShenzhen DL Testing Technology Co., Ltd.
Certified ByJADE YANG
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2025-08-07
Available2025-08-07
Created2025-07-18
Modified2025-07-18
Pages3
File TypeAdobe Acrobat PDF
File Size885027
File SHA-256adfce93cf21df9ebd1eef1ed987091fea15e0b88fdc047ec49193c902e477bb2
PDF Metadata Author3
PDF Metadata ProducerMicrosoft® Word 2016 Microsoft® Word 2016
FCC.gov SourcesFCC.gov 8549677
