FCC ID 2AF2K-WM415
WIFI Module
by Shenzhen KeZhongLong Optoelectronic Technology Co., Ltd.
Grantee Code: 2AF2K Product Code: WM415
Latest application date: 2015-11-06
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2015-11-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-11-06 | PDF 822.3 KB |
| Int photo | Internal Photos | 2015-11-06 | PDF 681.5 KB |
| Ext photo | External Photos | 2015-11-06 | PDF 487.9 KB |
| ID Label | ID Label/Location Info | 2015-11-06 | PDF 5.6 KB |
| ID Label Location | ID Label/Location Info | 2015-11-06 | PDF 264.8 KB |
| Test setup photos | Test Setup Photos | 2015-11-06 | PDF 355.4 KB |
| Test Report 1 | Test Report | 2015-11-06 | PDF 3.1 MB |
| Test Report 2 | Test Report | 2015-11-06 | PDF 2.9 MB |
| Confidential request letter | Cover Letter(s) | 2015-11-06 | PDF 27.6 KB |
| Modular approval letter (Ver 10.0) | Cover Letter(s) | 2015-11-06 | PDF 51.3 KB |
| POA | Cover Letter(s) | 2015-11-06 | PDF 793.4 KB |
| Statement | Cover Letter(s) | 2015-11-06 | PDF 14.9 KB |
| RF exposure | RF Exposure Info | 2015-11-06 | PDF 35.3 KB |
| Block diagram Metadata only | Block Diagram | PDF 173.2 KB | |
| SCH Metadata only | Schematics | PDF 152.7 KB | |
| OpDes Metadata only | Operational Description | PDF 32.6 KB |
Application Information
| Application ID | LV9Mc60eICR/U+qOlTDw1Q== |
|---|---|
| Final Action Date | 2015-11-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024890204 |
| Model | WM415 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WIFI Module |
| Responsible Party | Genglin Yan, General manager, cazi@kzlgd.com  , 0755-29353800 |
| Test Firm | Daniel zhu, Shenzhen Anbotek Compliance Laboratory Limited, Daniel.zhu@anbotek.com  , 86-755-26014771 |
| TCB Email | TCB@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Single modular approval for mobile platform. Power listed is the maximum conducted output power. Device contains 20 and 40 MHz signal bandwidth. This device is a 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| LV9Mc60eICR/U+qOlTDw1Q== | 2015-11-06 | Original Equipment |
Grants
TCB Grant - Application LV9Mc60eICR/U+qOlTDw1Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 11/06/2015 Application Dated: 11/05/2015 |
| Shenzhen KeZhongLong Optoelectronic Technology Co., Ltd. |
| 3/F, B5 Bldg., XinFu Industrial Zone, ChongQing |
| Road, FuYong Street, BaoAn District |
| Shenzhen, Guangdong, 518000 China |
| Attention: Genglin Yan , General manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF2K-WM415 |
| Name of Grantee: | Shenzhen KeZhongLong Optoelectronic Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WIFI Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.014 |
| Single modular approval for mobile platform. Power listed is the maximum conducted output power. Device contains 20 and 40 MHz signal bandwidth. This device is a 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application LV9Mc60eICR/U+qOlTDw1Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen KeZhongLong Optoelectronic Technology Co., Ltd. 3/F, B5 Bldg., XinFu Industrial Zone, ChongQing Road, FuYong Street, BaoAn District Shenzhen, Guangdong, 518000 China |
Date of Grant: 11/06/2015 Application Dated: 11/05/2015 |
| Attention: Genglin Yan , General manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF2K-WM415 |
| Name of Grantee: | Shenzhen KeZhongLong Optoelectronic Technology Co., Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | WIFI Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| MO | 15C | 2412.0 - 2462.0 | 0.014 |
| Single modular approval for mobile platform. Power listed is the maximum conducted output power. Device contains 20 and 40 MHz signal bandwidth. This device is a 2X2 MIMO. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
