ONIAM4 onia mini Teardown Internal Photos - FCC ID 2AF2SONIAM4
FCC ID 2AF2SONIAM4
Internal Photos
onia mini
Document preview loads when visible.
Document Details
| FCC ID | 2AF2SONIAM4 |
|---|---|
| Document ID | 3129203 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Document Title | Internal photos.hwp |
| Applicant | JUNGGAM Co.,Ltd |
| Equipment Class | onia mini |
| Product Code | ONIAM4 |
| Application ID | rhdvOmKSD7ql3NMNxJ4I7w== |
| Application Purpose | Original Equipment |
| Application Date | 2016-09-09 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0024911661 |
| Test Firm | Standard Engineering Co., Ltd. |
| Certified By | Sang Lim, Kwon CEO |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2016-09-09 |
| Available | 2016-09-09 |
| Created | 2016-09-09 |
| Modified | 2016-09-09 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 416329 |
| File SHA-256 | a94f0351029cb7fab90793db11ba65abb57cf95fce5a8961ba9124bb0205e947 |
| PDF Metadata Author | <B1E8BCF8C8A3> |
| PDF Metadata Producer | Acrobat Distiller 9.5.5 (Windows) <B1E8BCF8C8A3> |
| FCC.gov Sources | FCC.gov 3129203 |
