FCC ID 2AF5L-DXP1000DVR
7 inch Multimedia Unit with DVR & Radio
by NINGBO INNO ELECTRONICS TECH CO., LTD.
Grantee Code: 2AF5L Product Code: DXP1000DVR
Latest application date: 2015-10-26
Device Images
FCC ID Device Details
| FCC ID | 2AF5L-DXP1000DVR |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AF5L |
| Product Code | DXP1000DVR |
| Applicant Business | NINGBO INNO ELECTRONICS TECH CO., LTD. 🇨🇳 |
| Equipment Class | 7 inch Multimedia Unit with DVR & Radio |
| Test Firm | EMTEK (DONGGUAN) CO.,LTD |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-26 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-26 | PDF 1.8 MB |
| Int photo | Internal Photos | 2015-10-26 | PDF 1.3 MB |
| Ext photo | External Photos | 2015-10-26 | PDF 337 KB |
| ID Label | ID Label/Location Info | 2015-10-26 | PDF 661.9 KB |
| ID Label location | ID Label/Location Info | 2015-10-26 | PDF 112.8 KB |
| Test setup photo | Test Setup Photos | 2015-10-26 | PDF 165.5 KB |
| Test report | Test Report | 2015-10-26 | PDF 4.1 MB |
| Confidential request letter | Cover Letter(s) | 2015-10-26 | PDF 21.9 KB |
| Model difference letter | Cover Letter(s) | 2015-10-26 | PDF 56.8 KB |
| POA | Cover Letter(s) | 2015-10-26 | PDF 22.7 KB |
| RF Exposure | RF Exposure Info | 2015-10-26 | PDF 94.7 KB |
| Block diagram Metadata only | Block Diagram | PDF 15.1 KB | |
| SCH Metadata only | Schematics | PDF 1 MB | |
| OpDes Metadata only | Operational Description | PDF 114.9 KB |
Application Information
| Application ID | wnjG66YE9u2yH3Smsu+gog== |
|---|---|
| Final Action Date | 2015-10-26 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024951881 |
| Model | DXP1000DVR |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | 7 inch Multimedia Unit with DVR & Radio |
| Responsible Party | Xia Xiao, Quality department manager, xiaoxia8019@163.com  , 13777201065 |
| Test Firm | Sam Lv, EMTEK (DONGGUAN) CO.,LTD, sam.lv@emtek.com.cn  , 86-769-2807078 |
| TCB Email | TCB@siemic.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| wnjG66YE9u2yH3Smsu+gog== | 2015-10-26 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0041110 | 15C |
Grants
TCB Grant - Application wnjG66YE9u2yH3Smsu+gog==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 10/26/2015 Application Dated: 10/26/2015 |
| NINGBO INNO ELECTRONICS TECH CO., LTD. |
| NO.128 Huishui Road Luo Tuo Industrial Zone, |
| Zhen Hai |
| Ningbo, Zhejiang, 315202 China |
| Attention: Xia Xiao , Quality department manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF5L-DXP1000DVR |
| Name of Grantee: | NINGBO INNO ELECTRONICS TECH CO., LTD. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 7 inch Multimedia Unit with DVR & Radio |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.004111 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
EAS Grant - Application wnjG66YE9u2yH3Smsu+gog==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
NINGBO INNO ELECTRONICS TECH CO., LTD. NO.128 Huishui Road Luo Tuo Industrial Zone, Zhen Hai Ningbo, Zhejiang, 315202 China |
Date of Grant: 10/26/2015 Application Dated: 10/26/2015 |
| Attention: Xia Xiao , Quality department manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF5L-DXP1000DVR |
| Name of Grantee: | NINGBO INNO ELECTRONICS TECH CO., LTD. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 7 inch Multimedia Unit with DVR & Radio |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.004111 |
| Power listed is the maximum conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance |
| Mail To: |
