FCC ID 2AF5PMG7540
16x4 DOCSIS 3.0 Cable Modem plus AC1600 Router
by MTRLC LLC
Grantee Code: 2AF5P Product Code: MG7540
Latest application date: 2016-12-29
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-12-29 |
| 5180-5240 MHz | Original Equipment | 2016-05-03 |
| 2412-2462 MHz | Original Equipment | 2016-05-03 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-12-29 | PDF 2.3 MB |
| User Manual.PDF | Users Manual | 2016-05-03 | PDF 2.2 MB |
| Internal Photos.pdf | Internal Photos | 2016-05-03 | PDF 474.3 KB |
| External Photos.pdf | External Photos | 2016-05-03 | PDF 490.3 KB |
| Label and Location.pdf | ID Label/Location Info | 2016-05-03 | PDF 2 MB |
| Test Setup Photos | Test Setup Photos | 2016-12-29 | PDF 355.2 KB |
| Test Setup Photos.pdf | Test Setup Photos | 2016-05-03 | PDF 585.7 KB |
| Test Report DFS | Test Report | 2016-12-29 | PDF 3 MB |
| Test Report NII | Test Report | 2016-12-29 | PDF 532.8 KB |
| Test Report (5G_Band 1 and Band 4) Rev.2.pdf | Test Report | 2016-05-03 | PDF 1.4 MB |
| Test Report - FCC 15.247_WIFI Report 11b g n20 40 Report Rev.2.pdf | Test Report | 2016-05-03 | PDF 1.1 MB |
| Attestation DFS Master Declaration | Attestation Statements | 2016-12-29 | PDF 57.4 KB |
| Attestation statement - 802.11 Channel and Mode Declaration.pdf | Attestation Statements | 2016-05-03 | PDF 26 KB |
| Attestation statement - FCC DoC Template.pdf | Attestation Statements | 2016-05-03 | PDF 28.8 KB |
| Authorization Letter | Cover Letter(s) | 2016-12-29 | PDF 66.6 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-12-29 | PDF 65.5 KB |
| Cover Letter Description of Change | Cover Letter(s) | 2016-12-29 | PDF 22.5 KB |
| Confidentiaty Request - Long term.pdf | Cover Letter(s) | 2016-05-03 | PDF 30.6 KB |
| Cover Letter - Authorization letter.pdf | Cover Letter(s) | 2016-05-03 | PDF 29.4 KB |
| RF Exposure | RF Exposure Info | 2016-12-29 | PDF 61.4 KB |
| RF exposure information - MPE Report Rev.1.pdf | RF Exposure Info | 2016-05-03 | PDF 161.7 KB |
| Block Diagram.pdf Metadata only | Block Diagram | PDF 83.9 KB | |
| Schematics.pdf Metadata only | Schematics | PDF 809.2 KB | |
| Operational Description Software Security Metadata only | SDR Software/Security Inf | PDF 199.8 KB | |
| Technical Description Rev.2.pdf Metadata only | Operational Description | PDF 102.9 KB |
Application Information
| Application ID | DHYQs6vo7Xyso7gzNGyqLg== |
|---|---|
| Final Action Date | 2016-12-29 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0024953069 |
| Model | MG7540 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | 16x4 DOCSIS 3.0 Cable Modem plus AC1600 Router |
| Responsible Party | Andrew Pollock, andyp@minim.com  , 9784601299 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | tei@timcoengr.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device has 20 MHz, 40MHz and 80MHz bandwidth modes. Indoor use only. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| DHYQs6vo7Xyso7gzNGyqLg== | 2016-12-29 | Class II permissive change or modification of presently authorized equipment |
| XGOCevgobZV/OsESqhCrPA== | 2016-05-03 | Original Equipment |
| Abo8g1IFOMKZ72kDZ4e5Ng== | 2016-05-03 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application XGOCevgobZV/OsESqhCrPA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 05/03/2016 Application Dated: 04/28/2016 |
| MTRLC LLC |
| 275 Turnpike Street |
| Suite 101 |
| Canton, MA 02021 |
| Attention: Andrew Pollock |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF5PMG7540 |
| Name of Grantee: | MTRLC LLC |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 16x4 DOCSIS 3.0 Cable Modem plus AC1600 Router |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.324339 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.314051 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing and/or in accordance with FCC multi-transmitter product guidelines. This device has 20 MHz, 40MHz and 80MHz bandwidth modes. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application XGOCevgobZV/OsESqhCrPA==
