FCC ID 2AF5YCL-680
Multifunction Speaker
by Shenzhen YINLAIKE Electronic Technology CO., Ltd
Grantee Code: 2AF5Y Product Code: CL680
Latest application date: 2015-10-17
Device Images
FCC ID Device Details
| FCC ID | 2AF5YCL-680 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | 2AF5Y |
| Product Code | CL680 |
| Applicant Business | Shenzhen YINLAIKE Electronic Technology CO., Ltd 🇨🇳 |
| Related Domains |  elec-king.com |
| Equipment Class | Multifunction Speaker |
| Test Firm | Shenzhen CTB Testing Technology Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2015-10-17 | PDF 2.4 MB |
| Internal photos | Internal Photos | 2015-10-17 | PDF 717 KB |
| External photos | External Photos | 2015-10-17 | PDF 294.8 KB |
| Label | ID Label/Location Info | 2015-10-17 | PDF 10.8 KB |
| Label location | ID Label/Location Info | 2015-10-17 | PDF 47.2 KB |
| Test setup | Test Setup Photos | 2015-10-17 | PDF 798.9 KB |
| Test report part 1 | Test Report | 2015-10-17 | PDF 3 MB |
| Test report part 2 | Test Report | 2015-10-17 | PDF 2.5 MB |
| Cover letter | Cover Letter(s) | 2015-10-17 | PDF 43.6 KB |
| RF Exposure | RF Exposure Info | 2015-10-17 | PDF 70.4 KB |
| Block Diagram Metadata only | Block Diagram | PDF 218.1 KB | |
| Schematics Metadata only | Schematics | PDF 115.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 26 KB |
Application Information
| Application ID | B3FDh2QV5yR5SD8l8C1THA== |
|---|---|
| Final Action Date | 2015-10-17 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0024955262 |
| Model | CL-680 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Multifunction Speaker |
| Responsible Party | Cunzhi Wang, chris@elec-king.com , 15818596616 |
| Test Firm | Simon Lee, Shenzhen CTB Testing Technology Co., Ltd., 923129423@qq.com  , 13662574496 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| B3FDh2QV5yR5SD8l8C1THA== | 2015-10-17 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 2402-2480 MHz | 0.0017180 | 15C |
Grants
TCB Grant - Application B3FDh2QV5yR5SD8l8C1THA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Nemko North America, INC. 303 River Road Ottawa, Ontario, K1V 1H2 Canada |
Date of Grant: 10/17/2015 Application Dated: 10/17/2015 |
| Shenzhen YINLAIKE Electronic Technology CO., Ltd |
| Room 3213 Nan Guang Jie Jia Building Futian |
| District Shenzhen China |
| Shenzhen, China |
| Attention: Cunzhi Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF5YCL-680 |
| Name of Grantee: | Shenzhen YINLAIKE Electronic Technology CO., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Multifunction Speaker |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.001718 |
| Output power listed is conducted. |
EAS Grant - Application B3FDh2QV5yR5SD8l8C1THA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Shenzhen YINLAIKE Electronic Technology CO., Ltd Room 3213 Nan Guang Jie Jia Building Futian District Shenzhen China Shenzhen, China |
Date of Grant: 10/17/2015 Application Dated: 10/17/2015 |
| Attention: Cunzhi Wang |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | 2AF5YCL-680 |
| Name of Grantee: | Shenzhen YINLAIKE Electronic Technology CO., Ltd |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Multifunction Speaker |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.001718 |
| Output power listed is conducted. |
| Mail To: |
